Rice Lake 882IS Intrinsically-Safe 185288 Digital Weight Indicator with Battery Pack Charger & tilt Stand
The Hazardous Environment Instrumentation Solution
Designed for hazardous locations that are potentially explosive, the 882IS digital weight indicator is built to safely operate in these settings without sacrificing performance. With cFMus, ATEX and IECEx approvals, the 882IS is the industry’s choice for flammable and combustible applications such as fuel refineries, chemical plants, distilleries, textile manufacturing and more.
Safe, Accurate Weight Readings in Hazardous Locations
The intrinsically safe, auto-ranging power supply enables wiring to a single AC conduit line and seal from the safe area. An FM approved, rechargeable battery is also available for isolated power or movable applications.
The 882IS utilizes a backlit LCD display to maintain brilliant visibility for user-friendly operation, even in dimly lit areas. Its stainless steel enclosure provides superior protection from the elements.
Enhanced Connectivity
Expand flexibility with an optional safe area I/O Module, featuring a serial port, Ethernet TCP/IP and optional analog output or fieldbus cards for communication with printers, computers and other peripherals. A duplex fiber-optic port allows for electrically-isolated communication with the I/O Module.
To complete the IS entity approved system, Rice Lake offers FM/ATEX-approved load cells and junction boxes that interface with the 882IS indicator
FEATURES
- Seven-digit, seven-segment LCD display with white LED backlight
- Stainless steel NEMA IP66 enclosure
- T4 temperature rating
- Front panel digital calibration
- Numeric keypad (882IS Plus only)
- Duplex fiber optic interface
- Power ON/OFF; battery save mode
- I/O module option: one serial port, optional analog outputs, optional fieldbus cards
- FM Entity Approved for use in hazardous locations per Rice Lake Weighing Systems control drawing file numbers 180948, 182301, and 186430
OPTIONS
- Battery option, IS6V2 VDC
- Battery charger, 6 VDC
- Power supply, 882IS mb-EPS-100-240-X2, dual output 6.8 VDC 200mA
- Cable, M12 power 22 in hazardous location (for battery version)
- Cable, M12 power 10 ft hazardous location
- Cable, M12 power 50 ft hazardous location
- Cable, M12 power 100 ft hazardous location
- Tilt stand, 882IS battery option
- Module, 882 smart I/O interface
882IS/882IS Plus Hazardous (Classified) Location Electrical Equipment Per U.S., Canadian, ATEX and IECEx Requirements
| Certificate No: |
FM18US0195X, FM18CA0092X, FM18ATEX0047X, IECEX FMG 18.0018X |
| Approval Standards |
FM/cFM:
INTRINSICALLY SAFE
Class I,II,III, Division 1, Groups ABCDEFG T4
Class I, Zone 0 AEx/Ex ia IIC T4 Ga
Zone 20 AEx/Ex ia IIIC T135°C Da
Ta = -10°C to +40°C (14°F to 104°F)
ATEX/IECEx |
| Equipment Ratings |
II 1 G Ex ia IIC T4 Ga
II 1 D Ex ia IIIC T135°C Da |
Model IS6V2 (Battery) Hazardous Location Electrical Equipment Per U.S., Canadian, ATEX and IECEx Requirements
| Certificate No: |
FM18US0195X, FM18CA0092X, FM18ATEX0047X, IECEx FMG 18.0018X |
| Approval Standards |
FM/cFM:
INTRINSICALLY SAFE
IS for Class I,II,III, Division 1, Groups ABCDEFG T4
Class I, Zone 0 AEx/Ex ia IIC T4 Ga
Zone 20 AEx/Ex ia IIIC T135°C Da
Ta = -10°C to +40°C (14°F to 104°F)
ATEX/IECEx |
| Equipment Ratings |
II 1 G Ex ia IIC T4 Ga
II1 D Ex ia IIIC T135°C Da |
Model IS6V2 (Battery) Hazardous Location Electrical Equipment Per U.S., Canadian, ATEX and IECEx Requirements
| Certificate No: |
FM18US0195X, FM18CA0092X, FM18ATEX0047X, IECEx FMG 18.0018X |
| Approval Standards |
FM/cFM:
INTRINSICALLY SAFE
IS for Class I,II,III, Division 1, Groups ABCDEFG T4
Class I, Zone 0 AEx/Ex ia IIC T4 Ga
Zone 20 AEx/Ex ia IIIC T135°C Da
Ta = -10°C to +40°C (14°F to 104°F)
ATEX/IECEx |
| Equipment Ratings |
II 1 G Ex ia IIC T4 Ga
II1 D Ex ia IIIC T135°C Da |
Model mb-EPS-100-240-X2 (Power Supply) Hazardous Location Electrical Equipment Per U.S., Canadian, ATEX and ICEx Requirements
| Certificate No: |
FM18US0195X, FM18CA0092X, FM18ATEX0047X, IECEx FMG 18.0018X |
| Approval Standards |
FM/cFM:
Class I,II,III, Division 1, Groups ABCDEFG T4 with IS outputs for
Class I,II,III, Division 1, ABCDEFG
Class I, Zone 1, AEx/Ex mb [ia Ga] IIC T4 Gb
Zone 21, AEx/Ex mb [ia Da] IIIC T135°C Db
Ta = -10°C to +40°C (14°F to 104°F)
ATEX/IECEx |
| Equipment Ratings |
II 2(1) G Ex mb [ia Ga] IIC T4 Gb
II 2(1) D Ex mb [ia Da] IIIC T135°C Db |
|
