Ohaus AX622N-E Adventurer AX Precision Balance (30100635) with External Calibration 620 x 0.01 g and Legal for Trade 620 x 0.1 g
Striking the ideal balance between inventive features and functional, uncomplicated weighing capabilities, the OHAUS Adventurer incorporates all of the applications necessary for routine weighing and measurement activities. more ...
The Most Complete Balance in its Class Striking the ideal balance between inventive features and functional, uncomplicated weighing capabilities, the OHAUS Adventurer incorporates all of the applications necessary for routine weighing and measurement activities. With a color touchscreen, GLP/GMP compliance capabilities, two USB ports, ingenious draftshield, and much more, Adventurer is the most complete balance in its class
Standard Features Include:
Stability, Accuracy, and Fast Operation Ensure Optimal Weighing Results — This trio of characteristics ensures the most important aspects of routine laboratory weighing are covered: accurate results you can count on extremely quickly.
Color Touchscreen & Connectivity Options Power a Modern Weighing Experience — The wide viewing angle color touchscreen provides quick access to all of Adventurer’s applications, while dual USB ports with GLP/GMP tracking capabilities assist in the monitoring and reporting of data.
Space-saving Draftshield Improves User Experience and Accessibility — The two piece, top-mounted draftshield doors open wide on both sides, providing ample room for sample placement, and also reduce the footprint of the draftshield in the rear of the balance when open.
Stability, Accuracy, and Fast Operation Ensure Optimal Weighing Results in Routine Weighing Tasks
Delivers stable and reliable weighing results for routine weighing tasks Stabilization Time
Adventurer’s fast stabilization time improves productivity in the laboratory Calibration
External Calibration — Traditional calibration in which the operator manually calibrates the balance with their choice of calibration weight value to ensure accuracy available on every model.
AutoCal™ — Select models feature OHAUS’ automatic internal calibration system that performs routine maintenance by calibrating the balance daily.
Color Touchscreen Offers Easy and Fast Operation of Adventurer’s Applications
Operate and access Adventurer’s nine application modes and abundant features that eliminate the need to do several manual calculations through the modern color touchscreen
Operators can wear laboratory gloves while utilizing the touchscreen, eliminating the inconvenience and hazards associated with constantly putting on and removing gloves
In addition to the touchscreen, Adventurer also has six mechanical keys that provide tactile feedback and allow the operator to perform repetitive operations such as tare, zero, calibration, and print
Weighing - Determine the weight of items in the selected unit of measure.
Dynamic Weighing - Weigh an unstable load. Scale takes an average of weights over a period of time
Display Hold - Manually holds the last stable weight or highest weighing value on the display.
Parts Counting - Count samples of uniform weight.
Density Determination - Determine density of solids or liquid. With the weigh below hook, it’s possible to perform specific gravity tests for objects that cannot be easily placed on the weighing pan.
Totalization - Measure cumulative weight of multiple items. Cumulative total may exceed balance capacity.
Percent Weighing - Measure the weight of a sample displayed as a percentage of a preestablished Reference Weight.
Check Weighing - Compare the weight of a sample against target limits.
Formulation - For compounding and recipe making. The number of components can range from 2 to 50.
Equipped with the Connectivity and Functional Features Required in Laboratories
Dual USB Ports
A front USB host port is easily accessible and makes it simple to load data from the balance on to a flash drive without having to reach around to the back or move the balance
A second USB device is located at the rear of the balance that can be used to connect the balance to a PC
The connectivity options help meet traceability requirements in traditional installations
Real Time Clock with GLP/GMP Data
A real-time clock function keeps accurate time even during power loss and the GLP data capability has the ability to record Sample name, Project names and Balance ID’s to help meet traceability and compliance requirements
The cloning feature allows you to save user and application settings to a USB flash drive which can be easily used to configure additional Adventurer balances
Below Minimum Sample Weight Indication
When using the minimum weight feature, the display clearly indicates that your current sample weight is below your
Space-saving Draftshield Designed to Improve User Experience and Accessibility
Draftshield doors are constructed of two glass panels, reducing the space required on the lab bench when the doors are open
Wide door entry provides unobstructed access and allows larger weighing vessels to be easily placed on the pan, reducing the chance of accidental spillage
Easy to keep clean in order to ensure a safe workspace by minimizing contamination
2 Year Manufacture Warranty
Other Ohaus Adventurer AX Analytical and Precision Balances
AC Adapter Input: 100-240 VAC 0.3A 50-60 Hz AC Adapter Output: 12 VDC 0.84A
Full-Color Touchscreen WQVGA Graphic LCD
4.3 in / 109 mm (diagonal)
Base Housing (W×H×D)
13.93 x 13.39 x 9.05 in / 354 × 340 × 230 mm
13.93 × 3.94 × 9.05 in / 354 × 100 × 230 mm
RS232, USB Device, USB Host
50°F to 86°F/10°C to 30°C
Maximum relative humidity 80 % for temperatures up to 86°F/30°C
14°F/-10°C to 140°F/60°C at 10% to 90% relative humidity, non-condensing
20.0 × 15.4 × 20.9 in / 507 × 387 × 531 mm
22.0 × 15.5 × 11.9 in / 557 × 392 × 301 mm
Additional Features RS232 interface, integral weigh below hook, full housing in-use cover, removable stainless steel pan, die-cast metal bottom housing, security bracket, illuminated up-front level indicator, four adjustable feet, software lockout menus, stability indicator, software overload/underload indicators, user selectable environmental settings, audible indicator, user selectable brightness settings, auto dim, touchscreen calibration, auto tare, user selectable operating language (nine)
Approvals Metrology: NIST Handbook 44, Measurement Canada Weights and Measures Regulations (Class I, nmax 220000; Class II, nmax 52000) Product Safety: CSA C22.2 No. 61010-1, UL 61010-1, IEC 61010-1 Electromagnetic Compatibility: FCC Part 15 Class A, ICES-001 Class A, IEC 61326-1 (emissions Class B, immunity Industrial requirements)
OHAUS Value in a Full-Featured, Portable Printer The all-new SF40A combines high performance and multiple functions to offer OHAUS quality and durability in a portable dot-matrix impact printer. The SF40A offers advanced functionality in an easy-to-use and set up printer at an exceptional value. This versatile printer is ideal for use in conjunction with OHAUS balances and scales in laboratory, industrial, and educational applications to ensure accurate documentation of weighing results.
Standard Features Include
Multiple Application Modes and Features Support the Data Reporting Process — SF40A is equipped with statistics and totalization modes that provide additional functionality for QA/QC and reporting processes. SF40A also offers a real-time clock with battery backup and date and time on printouts
Easy Setup And Configuration Eliminate Wasted Time — Don’t let your printer inhibit the efficiency of your weighing process. OHAUS balances and scales improve productivity and increase throughput and SF40A speeds recordkeeping to keep your job on track and get it completed as proficiently as possible. PC configuration software makes connecting the printer between balance or scale and computer a fast and convenient process and also makes setting up date, time, and baud rate hassle-free. The SF40A combined with GLP/GMP data output can help meet traceability and compliance requirements.
Multi-Language Printing Supports Universal Operation — SF40A supports printing in the language of the connected device in 13 different languages.
Other Standard Features
Status indicator, compatible with continuous label paper, perform zero and tare operations directly from the printer. Full functionality with Discovery, Adventurer™ Pro, Explorer®, Navigator®, MB Series Moisture Analyzers, Trooper®, Ranger®, Valor™ 7000, Defender™ bench and floor scales and “T” Series indicators. Statistics and Totalization not supported on other OHAUS products with RS232.
Multi-Language Printing: English, Spanish, French, German, Italian, Chinese, Korean, Japanese, Russian, Polish, Portuguese, Hungarian and Czech.
Printing Method - Thermal
Power - DC 7V ±1V (Printing), use exclusive adapter (DC 7V 1.6A) Thermal paper
Operating Temperature - 30 - 104° F / 0 - 40° C
Dimensions (W x D x H) - 4.17 x 7. x 3.5 in / 106 x 180 x 88 mm
Weight - 1lb / 470 g
Safety Standards - CE Marking/TUV - GS/FCC Class, B/VCCI Class B (AC adapter PSE/UL/C - UL/TUV - GS)
