| MODEL |
DT2x |
| Print Method |
Direct Therma |
| Resolution |
203 dpi (8 dots/mm) |
| Print Speed |
7 IPS (177 mm/s)** |
| Print Width |
2.12" (54 mm) |
| Print Length |
Min 0.16" (4 mm)** / Max 68" (1727 mm) |
| Processor |
32 Bit RISC CPU |
| Memory |
Flash |
4 MB Flash (2 MB for user storage) |
| SDRAM |
16 MB |
| Sensor Type |
Fixed transmissive sensor, central aligned, adjustable reflective sensor |
| Media |
Types |
Continuous form, gap labels, black mark sensing, and punched hole; label length set by auto sensing or programming |
| Width |
Min 0.6" (15 mm) ~ Max 2.36" (60 mm) |
| Thickness |
Min 0.0024" (0.06 mm) ~ Max 0.008" (0.2 mm) |
| Label Roll Diameter |
Max 5" (127 mm) |
| Core Diameter |
1" (25.4 mm) , 1.5" (38.1 mm) |
| Printer Language |
EZPL, GEPL, GZPL Auto Switch |
| Interface |
USB 2.0 / Serial Port: RS-232 (DB-9) / IEEE 802.3 10/100 Base-Tx Ethernet port (RJ-45) |
| Control Panel |
One Tri-color LED: Power (Green, Orange, and Red) / Function Key: FEED |
| Power |
Auto Switching 100-240V AC, 50-60Hz |
| Real Time Clock |
Standard |
| Environment |
Operating Temperature |
41º F to 104º F / 5 º C to 40 º C |
| Storage Temperature |
-4º F to 122º F / -20 º C to 50 º C |
| Humidity |
Operation |
30 - 85%, non-condensing) |
| Storage |
10 - 90%, non-condensing |
| Approvals |
CE (EMC), FCC Class A, CB, cUL and CCC |
| Dimension |
0.015% / CTYP (SC~35C / 41F~95F) |
| Weight |
2.65 lbs / 1.2 kg |
| Options & Accessories |
Label Dispenser, Print Head, Labels |
