CAS DT2X-01 Thermal Label Printer for S2000 Jr - EB w/USB & JS21 |
|
| CAS DT2X-01 Thermal Label Printer for S2000 Jr w/USB & JS21 more ... |
|
Retail Storefront >
Deli Scales >
Labels
|
|
|
|
|
|
Features
Ultra-light and compact, the DT2x direct thermal printer works seamlessly with the versatile S2000 Jr Price Computing Scale. Fast print speeds The printer includes one standard label format on the new LST-8000B blank label.With /USB & JS21
Dimensions
X:
12.00
Y:
6.00
Z:
10.00
Weight:
6.00 lb
|
|
Specifications
| MODEL |
DT2X-01 |
| Print Method |
Direct Therma |
| Resolution |
203 dpi (8 dots/mm) |
| Print Speed |
7 IPS (177 mm/s)** |
| Print Width |
2.12" (54 mm) |
| Print Length |
Min 0.16" (4 mm)** / Max 68" (1727 mm) |
| Processor |
32 Bit RISC CPU |
| Memory |
Flash |
4 MB Flash (2 MB for user storage) |
| SDRAM |
16 MB |
| Sensor Type |
Fixed transmissive sensor, central aligned, adjustable reflective sensor |
| Media |
Types |
Continuous form, gap labels, black mark sensing, and punched hole; label length set by auto sensing or programming |
| Width |
Min 0.6" (15 mm) ~ Max 2.36" (60 mm) |
| Thickness |
Min 0.0024" (0.06 mm) ~ Max 0.008" (0.2 mm) |
| Label Roll Diameter |
Max 5" (127 mm) |
| Core Diameter |
1" (25.4 mm) , 1.5" (38.1 mm) |
| Printer Language |
EZPL, GEPL, GZPL Auto Switch |
| Interface |
USB 2.0 / Serial Port: RS-232 (DB-9) / IEEE 802.3 10/100 Base-Tx Ethernet port (RJ-45) |
| Control Panel |
One Tri-color LED: Power (Green, Orange, and Red) / Function Key: FEED |
| Power |
Auto Switching 100-240V AC, 50-60Hz |
| Real Time Clock |
Standard |
| Environment |
Operating Temperature |
41º F to 104º F / 5 º C to 40 º C |
| Storage Temperature |
-4º F to 122º F / -20 º C to 50 º C |
| Humidity |
Operation |
30 - 85%, non-condensing) |
| Storage |
10 - 90%, non-condensing |
| Approvals |
CE (EMC), FCC Class A, CB, cUL and CCC |
| Dimension |
0.015% / CTYP (SC~35C / 41F~95F) |
| Weight |
2.65 lbs / 1.2 kg |
| Options & Accessories |
Label Dispenser, Print Head, Labels |
|
|
|
|
|
|
|
Optional Accessories
more info
|
CAS LST-8000B-001 Case of 12 Rolls of Labels for CAS DT2X-01 Printer
LST-8000B-001
Includes: Weight, Unit Price & Total Price
Unit Switchable - Prints the unit that is selected on the scale (lb, oz, kg)
Header: Thank You, Footer: Have a Nice Day!
|
|
more info
|
CAS LST-8000B-002 Case of 12 Rolls of Labels for CAS DT2X-01 Printer
LST-8000B-002
Includes: Weight, Unit Price & Total Price
Unit Switchable - Prints the unit that is selected on the scale (lb, oz, kg)
Header: (CUSTOM) Footer: (CUSTOM)
|
|
more info
|
CAS LST-8000B-003 Case of 12 Rolls of Labels for CAS DT2X-01 Printer
LST-8000B-003
Includes: Weight, Unit Price & Total Price
Unit Switchable - Prints the unit that is selected on the scale (lb, oz, kg)
Time, Date
Header: (CUSTOM) Footer: (CUSTOM)
|
|
more info
|
CAS LST-8000B-004 Case of 12 Rolls of Labels for CAS DT2X-01 Printer
LST-8000B-004
Includes: Weight, Unit Price & Total Price
Unit Switchable - Prints the unit that is selected on the scale (lb, oz, kg)
Time, Date, & Tare
Header: (CUSTOM) Footer: (CUSTOM)
|
|
|
|
|
|
|
|
|
