Avery Berkel 6710 Metric Point of Sale Bench Scale 9504-16452, 15 kg x 0.005 kg |
|
| Avery Berkel Models 6710 is designed for use in cafeterias, convenience stores, delicatessens, restaurants, candy shops or anywhere space is a premium. more ... |
|
Retail Storefront >
POS >
Cash Register Scale
|
|
|
|
|
|
Features
Standard point-of-sale interface scale for
linking to electronic cash registers or POS
systems.
- Easy to Read Six-digit LCD external
display with large 0.5” characters,
tactile keys.
- Accurate and Reliable Quality load cell
and electronics ensure repeatable weight
measurements and troublefree operation.
- Easy to Install Bi-directional 9-pin
RS232 port. Interfaces to most electronic
cash registers and point-of-sale software
programs.
- Quick Disconnects
Makes all cable connections easy.
- OPOS Compatible OPOS developers
tool kit available for POS systems
integration.
Features & Benefits
- Auto Zero Tracking Zero light indicator
and manual control when out of range.
- Interface Protocols NCI, ECR, 8213
(Sharp), 2250 (Swintec), ATT, 0400
(Olympia)
- Alternate Calibration Points
Allows use of less than full capacity
weight for calibration.
- Construction (6702/6710) Stainless
steel weighing area with full skirt
around perimeter of base, except where
connectors are located at rear of scale.
(6720) stainless steel weight platter,
die cast aluminum base.
- Power
Input: 120 VAC (+10% -15%)/ 60 Hz
(±3 Hz)
Standard 3 wire with ground input
Output: 15 VDC @ 0.3 Amps minimum
Power cord: 6 foot
- Agency Approvals
NTEP COC # 95-070
Canada W&M, COC AM-5076
UL Listed, CSA certified power supply
| 6710 Series Scales |
| Part Number |
9504-16655 |
9504-16453 |
9504-16663 |
9504-16452 |
9504-13721 |
| Capacity |
15 lb x 0.005 lb |
30 lb x 0.01 |
7 kg x 0.002 kg |
15 kg x 0.005 kg |
15lb x 0.005 lb |
POSITOUCH Software
Included |
No |
Yes |
| Dimensions |
Weigh Platter: 10" x 10" (254 mm x 254 mm)
Remote Display Enclosure: 5.8" W x 3.0" H x
1.4" D max (147 mm x 76 mm x 35 mm)
Adjustable Height: 2.5" – 3.0" (63 mm – 76 mm) |
| Power |
Input: Wall mount transformer 120 VAC
(+10% -15%)/ 60 Hz (±3 Hz)
Standard 3 wire with ground input
Output: 15 VDC @ 0.3 Amps minimum |
| Display |
Six-digit LCD external display with large 0.5"
characters, tactile keys, 7 ft. cable and Velcro™ for mounting. |
| Interfaces |
RS-232, 4-bit parallel, 40-bit serial, and OPOS. |
| Auto Zero Tracking |
Zero light indicator and manual control
when out of range. |
| Construction |
Stainless steel weighing area with full skirt
around perimeter of base, except where connectors are
located at rear of scale. |
| Operating Environment |
41°F to 104°F (5°C to 40°C) (Class III device)
10% to 90% RH (non-condensing) |
| Certifications |
Legal for Trade, NTEP Class III,
USA COC #95-070A5
Canada: MOI approval #AM-5076 Rev. 2
Power Supply: UL Listed, CSA Certified |
Weight:
17.00 lb
|
|
