Specifications
| |
MS-70 |
MX-50 |
MF-50 |
ML-50 |
| Measurement Method |
400W straight halogen lamp heating system with SRA filter and SHS weighing technology |
| Maximum Sample Weight Capacity |
71 g |
51 g |
51 g |
51 g |
| Weight Resolution |
0.0001 g |
0.001 g |
0.002 g |
0.005 g |
| Moisture Content Display |
0.001 / 0.01 / 0.1 % |
0.01 / 0.1 % |
0.05 / 0.1 / 1 % |
0.1 / 1% |
| Moisture Content Accuracy - over 1 g |
0.05% |
0.10% |
0.20% |
over 1 g: 0.5% |
| Moisture Content Accuracy - over 5 g |
0.01% |
0.02% |
0.05% |
0.1% |
| Heating Technology |
Halogen lamp (straight type: 400 watt max, 5000 hours) |
| Drying Temperature |
30-200°C (1° C increments) |
30-200°C (1° C increments) |
50-200°C (1° C increment) |
| Memory of Measurement Programs |
20 sets |
10 sets |
5 sets |
| Measurement Programs |
Standard Mode, Automatic Mode, Quick Mode, Timer Mode, Manual Mode |
Standard Mode, Quick Mode, Measurement Mode |
| Measurement Mode |
Moisture content (wet or dry base), Dry content, Ratio, Weight |
Wet base, Dry base, Solid content, Ratio |
| Heating Mode |
Standard, Quick, Step, Ramp |
Standard / Quick |
| Pan Size |
85mm |
85mm |
85mm |
86mm |
| Communication Software |
WinCT standard |
WinCT Moisture Standard |
WinCT standard |
- |
| Display Type |
Large VFD |
| Interface |
RS-232C standard |
| Data Memory Function |
100 |
50 |
30 |
| Operating Temperature |
5°C ~ 40 °C (14°F ~ 104°F) |
| GLP/GMP/ISO |
Available |
| Self Check Function |
Standard |
| Communication Software |
WinCT-Moisture standard |
WinCT standard |
- |
| Sample Pan Size |
2.16 inches (0.85 mm) |
3.4 inches (0.86 mm) |
| Power |
AC 100V to 120V or AC 200V to 240V, 50/60 Hz, approximately 400 W |
| Dimensions |
5.46 W x 8.1 D x 4.4 H inches
(215 W x 320 D x 173 H) |
8.5 W x 12.6 D x 6.8 H inches
(215 W x 320 D x 173 H) |
| Standard Accessories |
20 Sample Pans, 2 Pan Handles, Tweezers, Spoon, Test Sample (30 g of Sodium Tartrate Dihydrate), CD-ROM Software (WinCT-Moisture for MS & MX, WinCT for MF), Glass Fiber Sheet, RS-232C cable (for MS, MX), Display Cover, Dust Cover, Instruction Manual, Quick Reference Card, Power Cable, Fuse |
|
