AND Weighing FZ-2000iWP Internal Calibration Balance, 2200 x 0.01 g |
|
| FZ-iWP - Water Proof/Dust Proof with Internal Calibration. For the user that wants it all, the FZ-iWP adds internal calibration to complement the IP-65 rated dustproof and waterproof features. Here is a balance that be used virtually anywhere. more ... |
|
Scales >
Laboratory >
Basic
|
|
|
|
|
|
Features
FZ-iWP - Water Proof/Dust Proof
with Internal Calibration
For the user that wants it all, the FZ-iWP adds internal calibration to complement the IP-65 rated dustproof and waterproof features. Here is a balance that be used virtually anywhere.
What does “IP65” mean? The International Protection (IP) Code, as defi ned by the international standard IEC 60529, specifi es the degrees of protection provided by enclosures. The two digits
next to IP indicate the levels of protection against solid foreign objects (first digit) and water (second digit). For example, a device rated as IP65 should permit no ingress of dust (level 6) and withstand water jetting from any direction (level 5).
Features
Standard RS-232C Interface
Standard RS-232C Interface with a PC, printer or other peripheral devices.
GLP/GMP/GCP/ISO Compliant
In accordance with GLP and LIMS regulations In accordance with GLP and LIMS regulations be printed out using A&D’s AD-8121B or a PC.
Auto Power OFF Function
The display switches OFF automatically when the balance is inactive for 10 minutes as a power-saving tool.
Multiple Weighing Units of Measurement
Programmable or standard weighing units of measurement can be selected; g, pcs, %, oz, lb, lb-oz, ozt, ct, mom, dwt, GN, tl, tol, mes and MLT.
Response Indicator Function
Selectable FAST, MID or SLOW response to suit weighing environment conditions.
Built-in Rechargeable Battery (FXi-09)
An optional Ni-MH rechargeable battery pack can be fi tted into the FX-i series for use without AC power and for mobile applications (10 hours charging time for 8 hours operation).
Product Features:
- Internal Calibration
- IP65 Water proof/Dust Proof
- Compact SHS (Super Hybrid Sensor) 1 Second Stabilization
- Vacuum flourescent display
- Multiple Weighing Units (g, oz, lb, lb-oz, ozt, ct, mom, dwt, GN, tl, tol, mes, pcs, % and MLT)
Weight:
10.00 lb
|
|
Other AND Weighing FZ-iWP - Internal Calibration Balances
|
Specifications
| |
FZ-120iWP |
FZ-200iWP |
FZ-300iWP |
FZ-1200iWP |
FZ-2000iWP |
FZs-3000iWP |
Capacity x
Resolution |
g |
122 x 0.001 |
220 x 0.001 |
320 x 0.001 |
1220 x 0.01 |
2200 x 0.01 |
3200 x 0.01 |
| oz |
4.30 x 0.00005 |
7.76 x 0.00005 |
11.28 x 0.00005 |
43.0 x 0.0005 |
77.6 x 0.0005 |
112.8 x 0.0005 |
| lb |
0.268 x 0.000005 |
0.485 x 0.000005 |
0.705 x 0.000005 |
2.68 x 0.00005 |
4.85 x 0.00005 |
7.05 x 0.00005 |
| lb-oz |
0lb, 4.30oz x 0.01oz |
0lb, 7.76oz x 0.01oz |
0lb, 11.29oz x 0.01oz |
2lb, 11.03oz x 0.01oz |
4lb, 13.60oz x 0.01oz |
7lb, 0.88oz x 0.01oz |
| ozt |
3.92 x 0.00005 |
7.07 x 0.00005 |
10.28 x 0.00005 |
39.2 x 0.0005 |
70.7 x 0.0005 |
102.8 x 0.0005 |
| ct |
610 x 0.005 |
1100 x 0.005 |
1600 x 0.005 |
6100 x 0.05 |
11000 x 0.05 |
16000 x 0.05 |
| dwt |
78.6 x 0.001 |
141.7 x 0.001 |
206.2 x 0.001 |
786 x 0.01 |
1417 x 0.01 |
2062 x 0.01 |
| GN |
1882 x 0.02 |
3395 x 0.02 |
4938 x 0.02 |
18827 x 0.2 |
33951 x 0.2 |
49383 x 0.2 |
| Counting Mode |
Min. Unit
Mass |
0.001g |
0.01g |
# of
Samples |
5, 10, 25, 50 or 100 pieces |
| Percent Mode |
Min. 100%
Ref. Mass |
0.100g |
1.00g |
Min. 100%
Display |
0.01%, 0.1%, 1% (depends on the reference mass stored) |
Repeatability
(Std. Deviation) |
0.001g |
0.01g |
| Linearity |
±0.002g |
±0.02g |
Stabilization Time
(typically set at FAST) |
Approx. 1 second |
Sensitivity Drift
(10°C to 30°C) |
±2ppm / °C |
| Operating Temp |
5°C to 40°C (41°F to 104°F), 85% RH or less (No condensation) |
| Display Type |
Vacuum Fluorescent Display (VFD) |
| Display Refresh Rate |
5 times / second, 10 times / second or 20 times / second |
| Std. Serial Interface |
RS-232C Interface |
| Weighing Pan |
130mm |
150mm |
| External Calibration |
100g
50g |
200g
100g |
300g
200g
100g |
1000g
500g |
2000g
1000g |
3000g
2000g
1000g |
| AC Adaptor |
Confirm that the adaptor type is correct for the local voltage and power receptacle |
| Power Consumption |
Approx. 11VA (supplied to the AC Adaptor) |
| External Dimensions |
193 (W) x 262.5 (D) x 84.5 (H) mm |
| Net Weight |
Approx. 2.5kg |
|
|
|
|
* within the 48 continental US States
|
|
