Mark-10 MGTC100 Digital Torque Gauge, 100 x 0.1 lbFin |
|
| The new Series MGTC Cap Torque Gauge is a quick and economical solution for basic handheld cap torque testing. This portable instrument eliminates the need to secure closures in a fixture or more elaborate testing system. more ... |
|
Test Equipment >
Force Gauges >
Force Gauges w Torque Sensors
|
|
Have Questions?
Our Staff will be glad to help |
|
|
|
|
|
|
|
|
|
Features
The new Series MGTC Cap Torque Gauge is a quick and economical solution for basic handheld cap torque testing. This portable instrument eliminates the need to secure closures in a fixture or more elaborate testing system. A dedicated remote torque sensor with Jacobs chuck is supplied with a universal grip for caps from 0.65 - 1.80 in (16.5 - 45.7 mm) diameter. The MGTC records both application and removal torque values (clockwise and counter-clockwise directions), and is available in three capacities from 12 to 100 lbin (135 to 1150 Ncm).
Features:
- Universal grip ideal for wide range of cap sizes
- Compact design - Small size allows for portability
- Peak memory for application and removal torque values
- Selectable units
- Measure in lbFin, kgFmm, or Ncm of measurement
- Simple to use
- Rugged aluminum housing
- Programmable automatic shutoff
- IPM - Intelligent Power Management
- Push-button calibration
- Battery or AC operation
- Accuracy: ± 0.5% of full scale ±1 digit
- Safe overload: 150% of capacity
- Cap diameter range: 0.65 - 1.80 in [16.5 - 45.7 mm]
- Battery life: 30 hours of continuous operation
- Environmental requirements: 40°F - 100°F [5°C - 45°C], <96% humidity (non-condensating)
| Model |
MGTC12 |
MGTC50 |
MGTC100 |
Capacity
x
resolution |
12 x 0.01 lbin
140 x 0.1 kgFmm
135 x 0.1 Ncm |
50 x 0.05 lbin
580 x 0.5 kgFmm
570 x 0.5 Ncm |
100 x 0.1 lbin
1150 x 1 kgFmm
1150 x 1 Ncm |
| Accuracy |
±0.5% of full scale ±1 digit |
| Cap diameter range |
0.65 - 1.80 in [16.5 - 45.7 mm] |
| Power |
AC or non-rechargeable battery |
| Battery life |
30 hours of continuous use |
| Units of Measurement |
lbFin/ozFin, kgFmm, Ncm (depending on model) |
| Safe overload |
150% of full scale (display shows “----” at 110% and above) |
| Environmental requirements |
40° F - 100°F [5°C - 45°C], <96% humidity (non-condensating) |
| Thermal effects |
Zero: 0.03% of full scale/°C, Span: 0.01% of full scale/°C |
Weight:
10.00 lb
|
|
|
|
|
|
|
