| Model |
69525 |
69526 |
69527 |
169707 |
169708 |
169709 |
| Capacity x Readability |
500 x 0.2 lb |
1000 x 0.5 lb |
2000 x 1 lb |
500 x 0.2 lb |
1000 x 0.5 lb |
2000 x 1 lb |
| Indicator |
IQ plus ® 590-DC |
482 Plus |
| Display |
1 in (24.5 mm) 6-digit Liquid Crystal Display (LCD) |
0.8 in (20 mm), 6-digit, 7-segment LCD backlit display, |
Units |
lb, kg |
lb, kg |
Communications |
RS-232 |
2 x RS-232 |
Indicator Rating/Material |
NEMA Type 4X/IP66, stainless steel |
NEMA Type 4X/IP66, heavy-gauge stainless steel |
Power: |
Powered by 6 C cell alkaline batteries for complete portability |
AC 110 V |
Base
Legal For Trade |
NTEP CC 98-004, Class III, 2,500 d
Measurement Canada AM-5218, (250 kg and 500 kg) Class III 2,500 d (1,000 kg) Class III 2,000 d |
Indicator
Legal For Trade |
NTEP CC 98-203, Class III/IIIL 10,000d
Measurement Canada AM-5300, Class III 10,000d, Class IIIHD 20,000d |
Measurement Canada AM-5892, Accuracy Class III/IIIHD, 10 000d
NTEP CC 12-123, Accuracy Class III/IIIL, 10 000d
OIML R76/2006-NL1-12.48, T5692, TC8322Accuracy Class III, 10 000d |
Standard Features |
- Full numeric keypad
- Keyboard entry of piece weight, tare weight, calibration and sample size
- Display tare button
- Powered by 6 C cell alkaline batteries for complete portability (batteries not included)
- (3) 300-character print ticket formats
- Power for (4) 350 ohm load cells or (8) 700 ohm load cells
- Supports 4- and 6-wire load cell connections
- EDP port for full duplex, RS-232 communications
- NEMA Type 4X/IP66-rated stainless steel enclosure
- LCD display, 1 in (24.5 mm), 6-digit
- AC adapter for 115 or 230 VAC power
- Configurable standby mode to prolong battery life
- RATTLETRAP® 3-stage digital filtering
- Configurable units multiplier
- Configurable analog-to-digital measurement rate
- Self-resetting thermal fuse
- Configurable with Revolution® software
|
- LCD backlit display, 0.8 in (20 mm), 6-digit, 7-segment
- Time and date, battery backed
- Local/remote operation
- Numeric keypad (482 Plus)
- Keyed entries for tare and setpoint values (482 Plus)
- 2 independent serial ports, RS-232 and 20 mA
- NEMA Type 4X/IP66 stainless steel washdown enclosure
- Password protection for user and configuration changes
- Selectable conversion rate and display update rate
- Hardware or audit trail metrology sealing
- Programmable ticket formats for gross, net, accumulator and setpoints
- 5 continuous stream formats
- Adaptive filter or rolling average filter
- Configurable with Revolution® software
- Operator functions through menu for audit trail, preset tare, unit ID, accumulator, time and date, setpoints, communications and print formats
- 8 setpoints, sequenced batch engine
|
Options (Call for more info) |
- |
- Analog output, 0-10 VDC, 0-20 mA, 4-20 mA, selection for 20% offset
- Relay output, 2 digital inputs, four dry contact relays (supports 2 boards)
- Ethernet TCP/IP and USB interface (requires cable)
- Battery, rechargeable lithium ion Power for 40 hours of battery life on one 350 ohm load Power-saving modes for sleep and wake-up threshold
|
| Indicator Specifications |
- Power: 9 VDC, provided by 6 C-cell alkaline batteries or AC adapter
- Power Consumption:
- 100 mA (100 hours with 4 load cells)
- 25 mA (300 hours with 1 load cell)
- Excitation Voltage: 5 VDC, 4 x 350 Ù or 8 x 700 Ù load cells
- Analog Signal Input Range: -2.5 mV – 22.5 mV
- Analog Signal Sensitivity:
- 0.3 ìV/graduation minimum
- 1.5 ìV/grad recommended
- Resolution:
- Internal resolution: 1 million counts
- Display resolution: 100,000d
- Counting Capacity: 100,000 pieces
- Measurement Rate: 30, 15, 71/2, 33/4 per second
- System Linearity: Within 0.01% of full scale
- Serial Communications: EDP/Printer port: Full duplex RS-232
- Display: 1 in (24.5 mm) 6-digit Liquid Crystal Display (LCD)
- Circuit Protection: RFI, EMI, ESD protection
- Annunciators: Units (lb/kg), piece count mode (PC), gross, net, standstill, center of zero, tare, low battery
- Keyboard: 19-key flat membrane panel, tactile feel
- Operating Temperature:
- Legal: 14° F to 104° F (-10° C to 40° C)
- Industrial: 14° F to 122° F (-10° C to 50° C)
- Weight: 6.5 lb (2.95 kg)
- Rating/Material: NEMA Type 4X/IP66, stainless steel
- Warranty: Two-year limited warranty
- Approvals:
- NTEP CC 98-203, Class III/IIIL 10,000d
- Measurement Canada AM-5300, Class III 10,000d, Class IIIHD 20,000d
- CE marked
- UL & C-UL listed
|
- Power:
- Line voltages: 90-264 VAC
- Frequency: 50 or 60 Hz
- Estimated battery life: 40 hours (350 ohm load)
- Excitation Voltage: 5 VDC, 8 x 350 Ù load cells
- Analog Signal Input Range: ±7 mV/V
- Analog Signal Sensitivity:
- 0.1 uV/graduation minimum,
- 0.5 uV/graduation recommended
- Resolution:
- Internal: 523,000 counts
- Disply: 100,000 graduations
- Measurement Rate: Selectable 5, 10, 20, 40 Hz
- System Linearity: Within 0.01% of full scale
- Circuit Protection: Immunity 10 V/m ESD ±10 KV air ±6 KV contact
- RFI Protection: Capacitor bypass and ESD suppressors
- Serial Output:
- Com 1: RS-232 full duplex
- Com 2: RS-232 full duplex or 20 mA simplex, continuous
- Both ports 1200, 2400, 4800, 9600, 19200, 38400 baud 7 or 8 data bits, even, odd or no parity
- Display: LCD backlit display, 0.8 in (20 mm), 6-digit, 7-segment
- Status Annunciators: Gross, net, center of zero, standstill, lb, kg, tare, preset tare
- Keyboard: Flat membrane panel, embossed keys, tactile feel
- (Optional) Analog Output: 16-bit resolution, voltage output 0-10 VDC, current output 0-20 mA / 4-20 mA
- (Optional) Relay Board:
- 2 opto-isolated, 5 to 24 VDC, active high inputs. 2 inputs (requires relay output option). Primary keys, pseudo functions, batching functions.
- (4) 30 VDC, 2 amp dry-contract relays
- (Optional) Ethernet and USB Board: USB 5-pin header for PC, printer or flash drive. Ethernet TCP/IP, RJ45 jack, server and client ports.
- Operating Temperature: Legal: 14° F to 104° F (-10° C to 40° C)
|
)
)
)
)
