Imada ZTA-0.4 Digital Force Gauge with Luminescent EL Display 7.0 x 0.01 oz |
|
| Imada ZTA Digital Force Gauges with Luminescent EL Display, User-Friendly, Multi-Language Menus Color-coded LED indicators and output signal for Go/No Go testing USB (virtual COM port), RS-232C, Digimatic and Analog outputs. Additional features including Display force and displacement data with Imada FA test stand and Export gauge memory or save continuous data to USB flash drives. more ... |
|
Test Equipment >
Force Gauges >
Digital Force Gauges
|
|
|
|
|
|
Features
Imada ZTA Digital Force Gauges with Luminescent EL Display, User-Friendly, Multi-Language Menus Color-coded LED indicators and output signal for Go/No Go testing USB (virtual COM port), RS-232C, Digimatic and Analog outputs
Imada digital force measurement gauges are state-of-the-art, instruments capable of the highly accurate measurements required in quality testing to determine the strength or functionality of a part or product.
Imada force measurement gauges check both compression and tension (push or pull). Standard and special attachments simply screw on to the threaded shafts to provide various ways to grip or test samples.
Imada digital force measurement gauges also output data for collection by data acquisition software in USB, RS232, Digimatic and analog formats.
ZTA Additional Features
- Display force and displacement data with Imada FA test stand
- Export gauge memory or save continuous data to USB flash drives
ZTS Standard Features
- EL electro luminescent display is highly visible in dark locations
- Multi-langauge program menus: English, Spanish, French, Chinese, German, Italian, Korean, Japanese
- Processes and transmits 2,000 data/sec.
- Color-coded LED indicators and output signal for Go/No Go testing
- Ergonomic design with non-slip grips, heavy duty metal construction
- Capacity up to 1,100 lbs (push/pull)
- Overload capacity 200% F.S.
- USB (virtual COM port), RS-232C, Digimatic and Analog outputs
- lbf, kgf, and N units are selectable
- 1,000 data memory for recall or download
- External switch display hold and clear
- Internal Ni-MH batteries or AC adapter
- Real time and peak mode (selectable)
- Overload alarm and output signal
- Kit includes, full set of attachments, ZT Logger data acquisition software, USB cable, AC adapter/charger, calibration cert traceable to NIST and carrying case.
Easy-to-use menus make programming simple in eight languages. Select units, reverse display, set high/low setpoints, and all other functions in plain language.
Electro luminescent EL display shows force value, unit, and peak, and can be configured with additional user-selectable data including memory data, +NG count, high/low setpoints, 1st and 2nd peaks, displacement value (using Imada test stand with FA option), etc.
Color-coded LED indicators alert the user to Go/NoGo conditions. Orange lights for less than low setpoint, green lights between high and low, and red for over the high.
Process and transmit 2,000 actual data per second, not just the peak from a high sampling rate. Optional Force Recorder data acquisition software is designed to process up to 2,000 data per second.
Display force and displacement data on ZTA gauges with Imada test stands equipped with FA option.
Save data to USB flash drives. Export peak data or capture continuous data at 100 data/second to flash drives with ZTA force gauges.
ZT Logger data acquisition software downloads data from the gauge memory or captures a continuous stream of data at 10 data/second. Zero the gauge or capture data while at the computer. All gauge programming can be set and saved from the software.
Weight:
10.00 lb
|
|
Other Imada ZTA Advanced Digital Force Gauge with Luminescent EL Display
|
Specifications
| Model |
ZTA-0.4 |
ZTA-1 |
ZTA-4 |
ZTA-11 |
ZTA-44 |
ZTA-110 |
ZTA-220 |
ZTA-550 |
ZTA-1100 |
Capacity x Resolution
Pounds/Ounces |
7.0 x 0.01 oz |
18.0 x 0.01 oz |
4.4 x 0.001 lb |
11 x 0.01 lb |
44 x 0.01 lb |
110 x 0.1 lb |
220 x 0.1 lb |
550 x 0.1 lb |
1100 x 1 lb |
Capacity x Resolution
Kilograms/Grams |
200 x 0.1 g |
500 x 0.1 g |
2 x 0.001 kg |
5 x 0.001 kg |
20 x 0.01 kg |
50 x 0.01 kg |
100 x 0.1 kg |
250 x 0.1 kg |
500 x 1 kg |
Capacity x Resolution
Newtons |
2 x 0.001 N |
5 x 0.001 N |
20 x 0.01 N |
50 x 0.01 N |
200 x 0.1 N |
500 x 0.1 N |
1000 x 1 N |
2500 x 1 N |
5000 x 1 N |
| Accuracy |
± 0.2% F.S., ± 1 LSD |
| Selectable Units |
lbf(ozf), kgf(gf) or Newtons |
| Overload Capacity |
200% of F.S. (Overload indicator flashes beyond 110% of F.S.) |
| Power |
Rechargeable Ni-MH battery pack or AC adapter |
| Battery Indicator |
Indicates three charge states high, med and low |
| Memory |
Non-volative, recall up to 1,000 data
Export gauge memory or save continuous data to USB flash drives |
| Setpoints |
Programmable high/low setpoints w/ color-coded LEDs & output signal |
| Outputs |
Outputs USB (virtual COM port), RS-232C, Digimatic and ± 2 VDC analog output |
| Operating Temp |
Operating Temp. 32° to 100°F (0° to 40°C) |
|
|
|
|
|
|
|
Optional Accessories
more info
|
Imada DB-1 Data Button
DB buttons work with Imada SW software to automate data collection from Imada force or torque gauges. Enter peak measurements into the spreadsheet and "zero" the gauge with a touch of the button. Minimize computer time and mouse useage.
Single channel mode -- collects force or torque data.
|
|
more info
|
Imada OH-1 Handle for DS2,ZTS,ZTA Gauges - Only with System
Optional handle for Imada DS2 gauges to facilitate large loads
|
|
more info
|
Imada SW-1X Force Data Acquisition Software
SW-1 is a highly customized Excel spreadsheet specifically designed for capturing and analyzing real-time data from Imada gauges with an RS-232C port.
SW-1 allows real time data from RS-232C instruments to be input directly into any Windows program – including Microsoft Excel. SW-1 inputs gauge readings in real time and provides a running log of all force measurements along with a chart of the data as well as statistical information including Min, Max, Mean, Median, Standard Deviation, Average Deviation and Variance.
Complete control of the gauge is provided through a set of “buttons” on the spreadsheet that enable easy editing of the sampling rate, force measurement units, peak/real time, tare and power off.
Other features include a memory download option for Z2, Z2S-DPU and Z2H gauges only. If desired, the entire stack can be saved to disk, analyzed or cleared. Because all data is entered directly into a standard Excel spreadsheet, you are virtually unlimited in your ability to analyze your force gauge data using all of the powerful tools available in Excel.
Hardware Requirements: Imada Gauge with RS-232C serial port, CB-203 or CB-204 cable, a Pentium or equivalent with 32MB RAM or better, a mouse and approximately 1 MB hard disk space.
Software Requirements: Windows 95, Windows 98, Vista, XP, Windows 7, Windows 8 or later
Excel ‘97 or later is Require
|
|
|
|
|
|
|
|
|
