Intercomp CS1500RFX - 184509-RFX LCD Crane Scale w/Handheld RFX Indicator, 1000 x 0.5 Ib

Name: Intercomp CS1500RFX - 184509-RFX LCD Crane Scale w/Handheld RFX Indicator, 1000 x 0.5 Ib
Brand: Intercomp
SKU: 37880
Price: 1975.50 USD
Availability: InStock
Rating: 5 (1 reviews)

The CS1500RFX™ High Performance Crane Scale features Fully Integrated RFX™ Wireless Weighing Technology and comes standard with Intercomp’s Handheld RFX™ Wireless Weighing Indicator. With a capacity range of 500lb (250kg) to 20,000lb (10,000kg), large, easy to read, LCD, NTEP Certified Models and use standard alkaline batteries, which last up to 3,000 hours of continuous use, the CS1500RFX™ is ideal for use in a variety of applications. more ...

Industrial Scales > Crane Scales & Dynamometers > Digital Crane Scales

Intercomp CS1500RFX - 184509-RFX LCD Crane Scale w/Handheld RFX Indicator, 1000 x 0.5 Ib

Specifications Chart View Full Detail Page

Legal for Trade

Have Questions?

email Us

Our Staff will be glad to help

Capacity x Readability
Non Legal Mode:1000 lbx 0.5 lb
Legal For Trade: 1000 lb x 0.5 lb

Optional Warranty

	CPS 879520004993 2 Year Extended Warranty for Portable Scales Under $2500	Price: $199.95

	CPS 879520005044 4 Year Extended Warranty for Portable Scales Under $2500	Price: $289.95

Features

Intercomp’s Handheld RFX™ Wireless Weighing Indicator fully controls scale functions, features USB/RS232 output, communicates with multiple scale units simultaneously and has a multitude of display options.

The CS1500™ is also offered in a non-RFX™ version with LED display for use where wireless signal is not required or prohibited

NTEP Certified Models Available

Features:

500 lb (250 kg) to 20,000 lb (10,000 kg) Capacities
Accuracy of ±0.1% of Reading
Large, Easy-to-Read, LED or LCD Display
NTEP Certified Models Available
Standard Alkaline D-Cell Batteries Last up to 3,000 Hours in Scale

Weight: 22.00 lb

1 Year Manufacture Warranty

Other Intercomp CS1500RFX

Image	Name			Price
	Intercomp CS1500RFX - 184508-RFX LCD Crane Scale w/Handheld RFX Indicator, 500 x 0.2 Ib SKU: 184508-RFX Capacity x Readability : 500 lb x 0.2 lb Legal For Trade: 500 lb x 0.2 lb More Info			$1,795.50
	Intercomp CS1500RFX - 184509-RFX LCD Crane Scale w/Handheld RFX Indicator, 1000 x 0.5 Ib SKU: 184509-RFX Capacity x Readability : 1000 lb x 0.5 lb Legal For Trade: 1000 lb x 0.5 lb More Info			$1,975.50
	Intercomp CS1500RFX - 184510-RFX LCD Crane Scale w/Handheld RFX Indicator, 2000 x 1 Ib SKU: 184510-RFX Capacity x Readability : 2000 lb x 1 lb Legal For Trade: 2000 lb x 1 lb More Info			$1,975.50
	Intercomp CS1500RFX - 184511-RFX LCD Crane Scale w/Handheld RFX Indicator, 5000 x 2 Ib SKU: 184511-RFX Capacity x Readability : 5000 lb x 2 lb Legal For Trade: 5000 lb x 2 lb More Info			$2,155.50
	Intercomp CS1500RFX - 184512-RFX LCD Crane Scale w/Handheld RFX Indicator, 10000 x 5 Ib SKU: 184512-RFX Capacity x Readability : 10000 lb x 5 lb Legal For Trade: 10000 lb x 5 lb More Info			$2,395.00

Specifications

CS1500 Crane Scales
Model	100661	100662	100663	100664	100665	100666	184508-RFX	184509-RFX	184510-RFX	184511-RFX	184512-RFX	184513-RFX
Capacity Graduation	500 x 0.2 lb 250 x 0.1 kg	1000 x 0.5 lb 500 x 0.2 kg	2000 x 1.0 lb 1000 x 0.5 kg	5000 x 2.0 lb 2500 x 1.0 kg	10,000 x 5.0 lb 5000 x 2 kg	20,000 x 10 lb 10,000 x 5 kg	500 x 0.2 lb 250 x 0.1 kg	1000 x 0.5 lb 500 x 0.2 kg	2000 x 1.0 lb 1000 x 0.5 kg	5000 x 2.0 lb 2500 x 1.0 kg	10,000 x 5.0 lb 5000 x 2 kg	20,000 x 10 lb 10,000 x 5 kg
Legal For Trade	NTEP #97-135A4
Weight	21 lb/10kg		25 lb/12kg	46 lb/20 kg		88 lb/40kg	22 lb/10kg			38 lb/17kg		45 lb/20 kg
General	Zero, lb/kg On, Off, Tare, Print, Mode, Set
Display	5 1/2 Digit, 0.8 Inch, 20 mm high LED Display
Indicator	lb/kg, Gross, Net, Total and Peak Hold						Intercomp 101225-RFX
Battery Life	Standard Alkaline D-Cell Batteries Last up to 90 Hours in Scales
Batteries	8 "D" Size disposable Alkaline dry cells or rechearable nicad cells (not included)
Resolution	20 bit A/D delivers over 1,000,000 internal counts
Auto-Zero	Satisfies all NIST/OIML requirements
Zero	Up to 100% excluding NIST/OIML units
Humidity	10 to 95% non-condensing
Temperature	Operating -4° to 140°F/- 20° to 60°C
Filtering	6-Pole, 10 Hertz low pass
Speed	3 Seconds to typical reading
Accuracy	+/- 0.1% of reading
Maximum Overload	500% of capacity
Enclosure	NEMA IV cast aluminum case
Hook or Eye	Crosby-Laughlin or equivalent
USB/RS232 Output	-						YES
Options	RS 232 Serial Output (sold separately) LED Display (sold separately) Direct 120/220 vold power supply (sold separately)						Printer
