AND SV-10A, Viscometers 0.3cP - 10,000 cP

A&D's own technology is setting a new standard for viscosity measurement! Speed? Accuracy? User-friendly? A&D’s highly sensitive, tuning-fork vibration viscometer*, the SV-A series, not only completely satisfies these basic requirements, but does more by offering users a number of additional benefits that were once unthinkable with a conventional viscometer. more ...
Scales > Test Stand > Test Stands
AND SV-10A, Viscometers 0.3cP - 10,000 cP

Specifications Chart View Full Detail Page


Call for more info
Download PDF
AND SV-10A, Viscometers 0.3cP - 10,000 cP

Price: $4,692.00


In Stock - Ships within 24 hours

Optional Accessories
AND Weighing Replacement TB-136C AC Adapter,120V AND Weighing Replacement TB-136C AC Adapter,120V , $43.00
AND Weighing SV-43 Extension Cable (5m) to connect the main unit and the display unit AND Weighing SV-43 Extension Cable (5m) to connect the main unit and the display unit , $299.25
AND Weighing SV-42 Analog Voltage Output (0~1V) AND Weighing SV-42 Analog Voltage Output (0~1V) , $655.50
AND Weighing SV-37 Water Jacket x 1pc, Small Sample Cup with Cover x 4pcs AND Weighing SV-37 Water Jacket x 1pc, Small Sample Cup with Cover x 4pcs , $180.50
AND Weighing SV-36 Positioning Fixer for Sensor Unit AND Weighing SV-36 Positioning Fixer for Sensor Unit , $171.00
AND Weighing SV-35 Sample cup, 13 ml, Glass x 1pc AND Weighing SV-35 Sample cup, 13 ml, Glass x 1pc , $270.75
AND Weighing SV-34 Small Sample Cup, 10 ml, with Cover, Polycarbonate x 10pcs AND Weighing SV-34 Small Sample Cup, 10 ml, with Cover, Polycarbonate x 10pcs , $80.75
AND Weighing SV-33 Sample Cup, 45 ml, with Cover, Polycarbonate x 10pcs AND Weighing SV-33 Sample Cup, 45 ml, with Cover, Polycarbonate x 10pcs , $99.75
A&D Weighing AX-USB-2920-25P  USB  to 25 pin RS-232  Converter A&D Weighing AX-USB-2920-25P USB to 25 pin RS-232 Converter , $77.00
AND Weighing AD-8127 Compact Multi-Function Printer AND Weighing AD-8127 Compact Multi-Function Printer , $695.00
A&D Weighing-AD1671- Anti-Vibration Table for Balances (Slab) A&D Weighing-AD1671- Anti-Vibration Table for Balances (Slab) , $1,495.00
AND TB-137 AC Adapter, 220V AND TB-137 AC Adapter, 220V , $49.00
AND AD-1682 Rechargeable Battery Pack AND AD-1682 Rechargeable Battery Pack , $465.00
AND Weighing SV-54 Standard Cup Set for SV-10A an SV-100A AND Weighing SV-54 Standard Cup Set for SV-10A an SV-100A , $636.50

View Features

AND Weighing
SKU: SV-10A

Features

A&Ds own technology is setting a new standard for viscosity measurement!

Speed? Accuracy? User-friendly? A&D’s highly sensitive, tuning-fork vibration viscometer*, the SV-A series, not only completely satisfies these basic requirements, but does more by offering users a number of additional benefits that were once unthinkable with a conventional viscometer.

2ml Sample Measurement
It is possible to perform viscosity measurements with sample liquid as small as 2ml (SV-1A).

Titanium Sensor Plates and Temperature Sensor
The sensors are made of titanium, which is anti-corrosive and resistant to various kinds of chemical substances.

X-Y-Z Stage
Fine position adjustment of the sample cup in three directions. This is especially useful when the sample cup is very small.

Wide-range, Continuous Measurements without Replacing the Sensor Plates
Unlike the rotational viscometer, which requires several different rotors to cover a wide range of measurements, the SV-A series is capable of using the same, fixed sensor plates to perform continuous measurements from very low to high viscosity [SV-1A: 0.3..1000mPa..s (cP), SV-10A: 0.3..10000mPa..s (cP), SV-100A: 1000..100000mPa..s (cP)].

Simultaneous Measurements of Temperature and Viscosity
It is widely known that viscosity is very temperature dependent (–2~–10%/°C). The SV-A series has a temperature sensor (0~160°C) right next to the viscosity sensor plates,enabling users to easily monitor the relationship between viscosity and temperature.

Sample Temperature Control
A water jacket is provided as standard to be used in conjunction with a commercially available constant heat water tank to heat the circulating system. This ensures that the sample remains at a constant temperature and that the temperature can be changed for viscosity measurement (0 ~ 100°C).

Standard Windows Communication Tools WinCT-Viscosity and a Serial-USB Converter
The graphing program RsVisco receives the viscosity and temperature data from the SV-A series and creates a graph on a personal computer in real time. As such, changes in viscosity and temperature over time as well as the correlation between viscosity and temperature can be observed visually.

Example Applications:

  • Measure the viscosity necessary for the correction of particle size distribution
  • Control the viscosity of resist liquids, inks, coating materials, adhesives, etc.
  • Control the viscosity of abrasives for semiconductors, ceramic materials, etc.
  • Measure the cure processes of polymers, soldering flux, proteins, and gelation point, etc.
  • Detect the cloud points of nonionic surface-active agents
  • Measure viscosity variation due to changes in temperature of a lubricant, engine oil, food, etc.
  • Quantify the ?gswallowability?h of beverages
  • Quantify the physical properties of biological substances, such as blood, etc.

Tuning-fork Vibration Viscometer
The tuning-fork vibration viscometer has a pair of thin sensor plates of the same natural frequency, which are driven with electromagnetic force to vibrate at the same amplitude. The viscidity produced between the sensor plates and the sample liquid is detected based on the amount of electronic current required to drive the sensor plates and maintain them at a constant amplitude.

  • The vibration viscometer is accredited as a Japan Calibration Service System (JCSS) standard device by the National Institute of Technology and Evaluation (NITE), along with the capillary viscometer and the rotational viscometer.
  • The sensor plates have very small thermal capacity and cause only minute displacement in the sample liquid, which prevents changes to the temperature and the physical properties of the sample.
  • Since the two sensor plates vibrate in reverse phase, it is possible to measure the viscosity of a sample while flowing or being stirred.

Very Quick Measurement
The initial viscosity coefficient will be indicated just 15 seconds after starting the measurement. The measured values will then be displayed in real time in response to the changes in viscosity.

High Accuracy
The SV-A series achieves an excellent repeatability of 1% of reading over its full measurement range.

Low Viscosity Measurement
No other viscometer is capable of measuring viscosity from as low as 0.3mPa..s.(SV-1A/10A)

Easy Calibration
Both one-point and two-point calibrations are possible using either viscosity standard liquids (optional) or samples of known viscosities. Simplified Calibration function, a one-key operation that utilizes purified water is also available for the SV-1A/10A.

Clearly Visible Display
Easy-to-read VFD for viscosity and temperature. Only 6 keys for simple operation.

Portable Sensor Unit
The sensor unit can be detached to perform measurements on location at a manufacturing factory, field research, etc. A portable carrying case is also provided as standard.


Weight: 20.00 lb
Other AND Weighing Viscometers SV-A Series

AND SV-10A

Viscometers 0.3cP - 10
000 cP

$4,692.00

You are viewing this product

AND SV-100A

Viscometers 10 P - 1
000 P (1
000 cP - 100
000 cP)

$4,692.00

AND SV-1A

Viscometers 0.3cP - 1000 cP

$5,396.00

Specifications

Model SV-1A SV-10A SV-100A
Viscosity Measurement Rang 0.3~1000mPa·s 0.3~10000mPa·s 1~100Pa·s
Measurement Method Tuning Fork Vibration Method (Natural Frequency at 30Hz)
Viscosity Measurement Unit mPa·s, Pa·s, cP, P Pa·s, P
Repeatability 1% of Reading (S.D., 20~30°C, No condensation)
Minimum Sample Amount 2ml~ 10ml~
Temperature Measurement 0~160°C / 0.1°C(32~320°F/0.1°F)
Display Vacuum Fluorescent Display (VFD)
Power Supply AC Adaptor (Approx. 14VA)
External Dimensions / Mass Main Unit: 112 (W)x132 (D)x291(H) mm / Approx. 0.8 kg
Display Unit: 238 (W)x132 (D)x170(H) mm / Approx. 1.3 kg
Standard Accessories Stand for Securing the Sensor Unit, X-Y-Z Stage, Cup Set
Software Set (including a Serial-USB Converter)
AC Adaptor, Connection Cable (1.5m), Carrying Case

Optional Accessories


AND Weighing Replacement TB-136C AC Adapter,120V
more info
AND Weighing Replacement TB-136C AC Adapter,120V
more info
Price: $43.00
In Stock
btn buy
AND Weighing Replacement TB-136C AC Adapter,120V
AND Weighing SV-43 Extension Cable (5m) to connect the main unit and the display unit
more info
AND Weighing SV-43 Extension Cable (5m) to connect the main unit and the display unit
more info
Price: $299.25
In Stock
btn buy
AND Weighing SV-43 Extension Cable (5m) to connect the main unit and the display unit
AND Weighing SV-42 Analog Voltage Output (0~1V)
more info
AND Weighing SV-42 Analog Voltage Output (0~1V)
more info
Price: $655.50
In Stock
btn buy
AND Weighing SV-42 Analog Voltage Output (0~1V)
AND Weighing SV-37 Water Jacket x 1pc, Small Sample Cup with Cover x 4pcs
more info
AND Weighing SV-37 Water Jacket x 1pc, Small Sample Cup with Cover x 4pcs
more info
Price: $180.50
In Stock
btn buy
AND Weighing SV-37 Water Jacket x 1pc, Small Sample Cup with Cover x 4pcs
AND Weighing SV-36 Positioning Fixer for Sensor Unit
more info
AND Weighing SV-36 Positioning Fixer for Sensor Unit
more info
Price: $171.00
In Stock
btn buy
AND Weighing SV-36 Positioning Fixer for Sensor Unit
AND Weighing SV-35 Sample cup, 13 ml, Glass x 1pc
more info
AND Weighing SV-35 Sample cup, 13 ml, Glass x 1pc
more info
Price: $270.75
Backordered
btn buy
AND Weighing SV-35 Sample cup, 13 ml, Glass x 1pc
AND Weighing SV-34 Small Sample Cup, 10 ml, with Cover, Polycarbonate x 10pcs
more info
AND Weighing SV-34 Small Sample Cup, 10 ml, with Cover, Polycarbonate x 10pcs
more info
Price: $80.75
In Stock
btn buy
AND Weighing SV-34 Small Sample Cup, 10 ml, with Cover, Polycarbonate x 10pcs
AND Weighing SV-33 Sample Cup, 45 ml, with Cover, Polycarbonate x 10pcs
more info
AND Weighing SV-33 Sample Cup, 45 ml, with Cover, Polycarbonate x 10pcs
more info
Price: $99.75
In Stock
btn buy
AND Weighing SV-33 Sample Cup, 45 ml, with Cover, Polycarbonate x 10pcs
A&D Weighing AX-USB-2920-25P  USB  to 25 pin RS-232  Converter
more info
A&D Weighing AX-USB-2920-25P USB to 25 pin RS-232 Converter
more info
Price: $77.00
In Stock
btn buy
A&D Weighing AX-USB-2920-25P USB to 25 pin RS-232 Converter
AND Weighing AD-8127 Compact Multi-Function Printer
more info
AND Weighing AD-8127 Compact Multi-Function Printer
more info
Price: $695.00
In Stock
btn buy
Features
  • Easy setting and operation with a numeric keypad and LCD display
  • Built-in calendar and clock for printing date and time at any time
  • Sends re-zero and weighing data request commands to the balance/scale
  • Clear and visible dot matrix printing, which also enables long-term preservation of the printed records
  • Compact and lightweight for portability and installation anywhere
  • Interval printing mode for printing weighing data at set intervals
  • Chart printing mode for printing time-series variations of weighing data
  • Dump printing mode to receive and print GLP/GMP/GCP/ISO compliant output from the balance/scale
  • Performs and prints the results of statistical calculation including standard deviation
  • Prints an ID number set for the printer at any time
  • Two types of RS-232C cables (D-Sub 25P and D-Sub 9P) provided as standard to connect to balances/scales with different interfaces*
  • Receives a print, paper feed, print statistical calculation results, print total, re-zero, or weighing data request command from the optional foot switch (AX-SW128)
Character specifications 7 × 9 dots, 1.6 (W) × 3.2 (H) mm
Printing speed Approx. 1.6 lines/second
Paper feeding speed Approx. 4 lines/second
Number of characters printed 24 characters/line
Printer paper width 57.5 mm
Operating environment 0 to 40 °C/32 to 104 °F, 35 to 85%RH (no condensation)
Storage environment -20 to 60 °C/-4 to 140 °F, 10 to 90%RH (no condensation)
Interface RS-232C (D-Sub 9P, male) / Current loop (DIN)
Power supply AC adapter
Size / weight 174 (W) × 141 (D) × 87 (H) mm / approx. 500 g
Standard accessories Ink ribbon (1 pc), plain printer paper (1 roll), AC adapter, AC adapter label, instruction manual, two RS-232C cables (D-Sub 25P and D-Sub 9P)*
A&D Weighing-AD1671- Anti-Vibration Table for Balances (Slab)
more info
A&D Weighing-AD1671- Anti-Vibration Table for Balances (Slab)
more info
Price: $1,495.00
In Stock
btn buy
Maximum loading capacity approximately 40 kg
Materia natural granite
Dimensions 460 W x 400 D x 70 H mm
Weight approximately 27 kg
AND TB-137 AC Adapter, 220V
more info
AND TB-137 AC Adapter, 220V
more info
Price: $49.00
In Stock
btn buy
AC Adapter, 220V for AND Weighing balances
AND AD-1682 Rechargeable Battery Pack
more info
AND AD-1682 Rechargeable Battery Pack
more info
Price: $465.00
In Stock
btn buy
Rechargeable Battery Pack for AND Weighing balances
AND Weighing SV-54 Standard Cup Set for SV-10A an SV-100A
more info
AND Weighing SV-54 Standard Cup Set for SV-10A an SV-100A
more info
Price: $636.50
In Stock
btn buy
Standard Cup Set for SV-10A/100A (SV-54)
  • Sample cup:
    • 45 ml, Polycarbonate × 5
    • 10 ml, with cover, Polycarbonate × 5
    • 13 ml, Glass × 2
  • Glass sample cup holder, Stainless steel × 1
  • Water jacket × 1
