View Specifications Chart
|
|
|
Detecto's MedVue® medical weight analyzer is utilized on select clinical scales. The MedVue® features a striking blue 3.5-in-wide by 3-in-high backlit LCD display screen with nearly 1-in-high weight digit readouts for easy visibility. The MedVue’s 350-degree swivel mounting bracket allows the display to be tilted and rotated into position wherever it is the most convenient for the medical professional and/or patient to view. A host of other benefits include 14-digit patient ID which may be entered via the alphanumeric keypad, 99 stored tare weights, 200 stored transactions, 1LOOK display, and four different languages available in set-up (English, Spanish, French, and German). The MedVue® offers a host of both wired and optional wireless connectivity for sending measurement data to
Versatile Connectivity - DETECTO's MedVue medical weight analyzer offers a host of different options, both wired and optional wireless, for DETECTO scales to connect with multiple devices for efficient EMR/EHR.
Connect with:
- Printers
- PCs
- Networks
- Tablets
- Bar Code Scanners
- Even Mobile Phones
BENEFITS OF WI-FI CONNECTIVITY - DETECTOs MedVue offers optional Wi-Fi connectivity with up to 20 ft. range (varies depending upon environmental conditions). Wi-Fi offers a number of benefits over Bluetooth, including greater range and security.
Almost every MedVue port may be used simultaneously (with the exception of Ethernet and Wi-Fi connections).
For instance, a printer could be connected to the serial port, PC connected to the USB port, while a tablet is connected via Wi-Fi all at the same time. DETECTOs model P50 printer offers plug-and-play compatibility with the MedVue
350-Degree Swivel Mounting Bracket (not included) - Enjoy freedom of movement wherever you need to position the display with the MedVues 350-degree tilt-and-swivel mounting bracket.
EASY SET-UP NAVIGATION -
DETECTOs MedVue indicator features a tiered menu system with up/down navigation controls to quickly update any settings you wish to change, such as converting to kilograms-only weighing or lowering the backlight intensity to make the batteries last longer
MULTIPLE LANGUAGE SETTINGS -
DETECTOs MedVue features user-prompting in four different languages:
- English
- Spanish
- French
- German
- 14-Digit Patient ID
- 350-Degree Swivel Mounting Bracket (not included)
- 6 AA Batteries (not included)
- 99 Stored Tare Weights
- BMI Calculation
- EMR/EHR Ready
- Nearly 1-in-High Weight Readouts
- NTEP Legal for Trade
- RS232 Serial and USB Ports Standard
- Sturdy Steel Construction
- Wi-Fi and Ethernet Optional
| model |
MV1 |
MV1-C |
$800.88
|
$790.56
|
| STANDARD FEATURES |
Units Locking
Auto Shut-Off
Selectable Sleep-Mode
Selectable Filtering
99 Tare Storage
Serial I/O (Input/Output)
USB Device Port
Height Rod Port (for Optional Detecto Digital Height Rod)
200 Transactions Stored
|
| Power Requirements |
6 "C" cell Alkaline, Ni-Cad or NiMH batteries (not included) OR an optional 110-240 VAC 50/60 Hz 12 VDC 1.25A wall plug-in AC power adapter (DETECTO part number MV1PWR) |
| Wi-Fi/Bluetooth Connectivity |
- |
YES |
| Display |
Overall Display Size: 3.5 inch W x 3 inch H (89 mm W x 76 mm H) backlit blue LCD
Weight: 5 digit, seven segment, 0.875 inch (22.23 mm) high LCD
Height: 4 digit, seven segment, 0.5 inch (12.7 mm) high LCD
BMI: 3 digit, seven segment, 0.5 inch (12.7 mm) high LCD
ID: 14 digit, 14 segment, 0.35 inch (8.89 mm) high LCD |
| Battery Life |
7,560 weighments (with backlight fully ON) / 10,620 weighments (with backlight fully OFF) |
| Sensitivity |
0.5 uV/division (0 to 3.0 mV/V), Class III |
| Operating Temperature |
14 to 104 ºF (-10 to +40 ºC) |
| Signal Input Range |
0 to 15mV max. |
| Transducer Excitation |
5.0 VDC |
| Number of Load Cells |
up to 4 each 350 Ù |
| Load Cell Cable Length |
30 feet (9 meters) max. |
| Capacities |
Weight: 10,000 divisions commercial
Height: 0 - 9 11.9"
BMI: up to 999 |
| Resolution |
10,000 divisions |
| Legal For Trade |
NTEP Certificate of Conformance Number #13-011
Measurement Canada #AM-5896 |
| Division Value |
1, 2 or 5 x 1, 0.1, 0.01, 0.001 |
| Sample Rate |
1 to 100 samples per second selectable |
| Auto Zero Range |
0.5 or 1 through 9 divisions |
| Weighing Units |
Pounds (lb), Pounds/Kilograms (lb/kg), Kilograms (kg) and Kilograms/Pounds (kg/lb) |
| Keyboard |
Membrane type with 19 keys |
| Enclosure Size |
9.8 inch W x 6.8 inch H x 1.8 inch D (248.9 mm W x 172.7 mm H x 45.7 mm D) |
| Construction |
Painted steel |
| OPTIONAL FEATURES |
MVIP Ethernet Option
Detecto DHR (Digital Height Rod)
MV1PWR, 12VDC AC Power Adapter
Welch Allyn® WACONNECT
|
|
