| Model |
UFM-B30 |
UFM-B60 |
UFM-B150 |
UFM-F30 |
UFM-F60 |
UFM-F120 |
UFM-F300 |
UFM-L60 |
UFM-L120 |
UFM-L300 |
UFM-L600 |
| Model |
3-UFM-S302-112 |
3-UFM-S605-112 |
3-UFM-S150-112 |
3-UFM-S301-112 |
3-UFM-S602-112 |
3-UFM-S120-112 |
3-UFM-S300-112 |
3-UFM-S60L-112 |
3-UFM-S12L-112 |
3-UFM-S30L-112 |
3-UFM-S600-112 |
| Price |
$585.49
|
$585.49
|
$585.49
|
$707.00
|
$707.00
|
$707.00
|
$707.00
|
$873.60
|
$873.60
|
$873.60
|
$873.60
|
| Capacity x Readability |
60 x 0.02 lb
30 x 0.01 kg |
150 x 0.05 lb
60 x 0.02 kg |
300 x 0.1 lb
150 x 0.05 kg |
60 x 0.01 lb
30 x 0.005 kg |
120 x 0.02 lb
60 x 0.01 kg |
250 x 0.05 lb
120 x 0.02 kg |
600 x 0.1 lb
300 x 0.05 kg |
120 x 0.02 lb
60 x 0.01 kg |
250 x 0.05 lb
120 x 0.02 kg |
600 x 0.1 lb
300 x 0.05 kg |
1200 x 0.2 lb
600 x 0.1 kg |
| Platform Size (W x D x H) |
13 x 17.7 x 3.5 inches
330 x 450 x 90 mm |
16.5 x 20.5 x 4.5 inches
420 x 520 x 120 mm |
19.7 x 23.6 x 4.5 inches
500 x 600 x 120 mm |
| Legal for Trade |
NTEP CoC #04-100
|
| Divisions |
3,000 |
6,000 |
| Weighing Units |
lb, kg |
| Functions |
Accumulation |
| NEMA / IP Rating |
NEMA 4X / IP 67 Protection |
| Tare Range |
To capacity by subtraction |
| Power Source |
Built-in rechargeable battery or external power adapter (included) |
| Construction |
Stainless steel platform and cast aluminum base |
| Display |
2 inch / 50.8 mm, 7 segment, wide viewing angle backlit LCD |
| Overall Dimensions (W x D x H) |
13 x 20.7 x 28.3 inches
330 x 525 x 720 mm |
16.5 x 23.5 x 33.9 inches
420 x 596 x 860 mm |
19.7 x 25.5 x 33.9 inches
500 x 647 x 860 mm |
| Operating Environment |
32ºF to 104ºF |
| Connectivity |
RS232 interface confi gurable, for printer or computer interface |
| Net Weight |
24.2 lb / 11 kg |
24.2 lb / 11 kg |
56 lb / 25.4 kg |
| Shipping Weight |
30 lb / 13.6 kg |
30 lb / 13,6 kg |
63 lb / 28.4 kg |
| Options |
Weatherproof indicator cover, printer, dry cell battery pack, desk mount indicator, wheel kit |
| Country of Origin |
Taiwan |
Taiwan |
Taiwan |
Taiwan |
Taiwan |
Taiwan |
Taiwan |
Taiwan |
Taiwan |
Taiwan |
Taiwan |
| Features |
Benefits |
| Overload and shock protection mechanism |
Protects against excessive loads and shock applied to platform |
| Heavy duty rugged construction |
Will withstand harsh industrial operation |
| Low profile, compact size |
Space saving, easy to load and unload |
| Large backlit LCD display with wide viewing angle |
Easy to see weight values from a distance, reduces mistakes |
| Display reads in lb and kg |
Flexibility of operation |
| Built-in rechargeable battery or external power adapter |
Portability. Battery operation minimum 100 hours(without backlight) |
| Accumulation function |
Allows you to add together consecutive weights to arrive at a total |
| Zero tracking |
Ensures that you always start weighing at zero |
| Automatic power save |
Conserves battery power |
| Low battery indicator / charge status indicator |
Alerts you to charge the battery, saving downtime |
| Easy calibration function |
Ensures accuracy |
| Gravitational correction software |
Enables you to input different G acceleration factors |
| Adjustable feet and spirit level |
Scale remains level for accurate results on uneven working surfaces - Anti-slip |
| Digital motion filtering |
Enables animal weighing or can compensate for harsh environmental conditions |
| Optional automatic tare |
Enables you to disregard the fi rst item placed on the platform |
| In use cover (for indicator) |
Protects indicator from damage and dirt |
