Chatillon ML-3317 TT Pneumatic Test Stand, Hand Operated

Chatillon ML-3317 TT Pneumatic Test Stand, Hand Operated

View Full Detail Page

Have Questions?
Call USoremail Us
Our Staff will be glad to help

Chatillon ML-3317 TT Pneumatic Test Stand, Hand Operated
FREE Ground Shipping
(48 US States Only)

Price: $6,589.00

Available to Ship

View Features

Chatillon Ametek
SKU: ML-3317


The Chatillon TT-series test stand is a pneumatically-operated instrument for measuring breaking strength of electrical leads, terminals, connectors, wire wraps, etc. It is ideal for areas where intrinsic safety is required.

The Chatillon TT pneumatic test stand is capable of either tensile or compression testing. The rapid test speed makes it ideal for production line testing, incoming inspection testing or the research and developement laboratory. The tester has a 6 (15 cm) test stroke and a hydro-check valve adjustment for controlling ram speeds as low as 0.1 inch per minute. The test stand meets MIL-T-7928 (ASG) requirements for crimped, solderless lugs. This test stand also feasures an automatic retracting steel jaw.

The Chatillon TT Test stand operates using clean, dry air with maximum air pressure up to 160 PSIG (121.2 bar).

Capacity: Up to 500 lb (2.5 kN)


  • Easy to use, rugged construction
  • Meets MIL-T-7928 (ASG) requirements
  • 6 (15cm) stroke
  • Precise ram speed control
  • Independant return stroke speed
  • Automatic retracting steel jaw
  • Intrinsically safe
  • Maintenance free design




Tester with Hand-operated Actuator


Tester with Foot Pedal Actuator

1 Year Manufacture Warranty
Other Chatillon Ametek Pneumatic Test Stands
Chatillon ML-3317 TT Pneumatic Test Stand, Hand Operated
Chatillon ML-3317
TT Pneumatic Test Stand
Hand Operated


You are viewing this product
