ALE provides three advantages as key value. ALE series is new answer to optimized weighing operation in the laboratory. Legal for Trade and RS232C and USB are installed as standard. Short stabilization time is indispensable for efficient weighing operation.
Minimize operation time with "Free keys"
Three keys on the front can work as "free keys". You can assign short-cut of often used functions on these keys. You don't need to push keys many times and minimize operation time.
Compact housing
ALE is the most space-saving precision balance. You can install the balance wherever you want, even in very small laboratory.
Short stabilization time
We have considerably reduced stabilization time by improved filtering technology. Short stabilization time is indispensable for efficient weighing operation.
Battery drive
ALE can be operated with dry-cell batteries thanks to low power consumption in tuning-fork sensor unit. Battery is useful also as reserve electric power
Software applications
Specific gravity measurement, formulation, parts counting, etc... Much applications are available with comfortable operation
Communication with outside devices
RS232C and USB are installed as standard to connect to outside devices like PC and printer. Extension RS232C, ethernet and relay contact can be available as additional option.
Vibra® Tuning Fork Sensor
Reads in g, ct, lb, oz t, GN, dwt, mom, mg, oz
Configurable RS232 Interface, Windows® Compatible
Checkweighing, %, Animal Weighing, Accumulation, Density, GLP Compliant Formulation, Statistics, Specific Gravity
Counting Feature NTEP Approved to 0.01 g for Pharmacy Filling
Bar Graph Indicator for Capacity Usage
HI-LO-GO Comparative Function
Below Balance Weighing with Optional Kit
Free Programmable Keys
E=D Dispensary Scales
Model
ALE-322NC
ALE-1501NC
Price
Selected
$1,026.31
Add to Cart
$870.35
Add to Cart
Standard
320 x 0.01 g
1500 x 0.1 g
Legal For Trade
E=D NTEP COC #17-061A2 - Measurement Canada AM6153 - Class II
Legal for Trade
320 x 0.01 g
1500 x 0.1 g
Calibration
External calibration
Displayed Divisions
32,000
150,000
Linearity
+ 0.02
Stabilization Time
< 1.5 seconds
Weighing Units
g, ct, lb, oz, gr
Power Source
External Power Adapter (included) or Dry Cell Batteries (4x AA Batteries)
Construction
Stainless Steel Pan & ABS Housing
Display
Backlit LCD w/ Configurable Soft Keys
Connectivity
Bi-Directional RS232 Interface, USB, & Bluetooth (only ALE-322NC)POS Ready w/ Windows, iOS, & Android
CALL
Pan Size
4.65" Ø / Ø 118 mm
6.3" x 6.3" / 160 mm X 160 mm
Dimensions
7" x 9" x 7.9" / 180 mm x 230 mm x 200 mm
7" x 9" x 7.9" / 180 mm x 230 mm x 200 mm
Operating Environment
32º - 104º F Non-Condensing R.H. < 85%
Net Weight
4 lb / 1.81 kg
Shipping Weight
9 lb / 4.08 kg
Net Weight
2.86 lb / 1.3 kg
Options (Call/email)
Ethernet or Relay Contact (only one option per unit), Specific Gravity Measurement Kit, Underweighing Hook, Carrying Case
Country of Origin
Japan
Features
Benefits
E=D NTEP Readability
NTEP Certified for Legal for Trade applications such as Cannibis.
Configurable RS232 Interface & USB
Allows Communication w/ Peripheral Data Collection & Printing Instruments
In Use Dust Cover
Protects balance from spillage & contamination
Easy Calibration
Ensures accuracy & repeatability
Soft Keys
Accessibility to different functions to be displayed on the home
Screen
Screen w/ one simple press.
Portability
Can be used w/ 4x AA houshold batteries
NTEP/MC Certification
Legal for Trade in the USA & Canada NTEP: 17-061A2 MC: AM6153
Device Compatible
Bluetooth Connectivity (ALE-322NC only – supply chain constraints)
Model
ALE-223
ALE-323
ALE-623
ALE-1502
ALE-2202
ALE-3202
ALE-6202
ALE-8202
ALE-15001
Price
$1,005.01
Add to Cart
$1,061.41
Add to Cart
$1,320.35
Add to Cart
$887.07
Add to Cart
$1,033.21
Add to Cart
$1,089.61
Add to Cart
$1,351.12
Add to Cart
$892.20
Add to Cart
$946.04
Add to Cart
Standard
220 x 0.001 g
320 x 0.001 g
620 x 0.001 g
1500 x 0.01 g
2200 x 0.01 g
3200 x 0.01 g
6200 x 0.01 g
8200 x 0.1 g
15000 x 0.1 g
Legal For Trade
NTEP COC #17-061
Legal for Trade
220 x 0.01 g
320 x 0.01 g
620 x 0.01 g
1500 x 0.1 g
2200 x 0.1 g
3200 x 0.1 g
6200 x 0.1 g
8200 x 1 g
15000 x 1 g
Calibration
External calibration
Repeatability (Std. Dev.)
+ 0.001 g+ 0.01 g
Linearity
+ 0.001 g+ 0.01 g
Stabilization Time
< 1.6 seconds< 1.6 seconds
Weighing Units
g, ct, lb, oz t, GN, dwt, mom, mg, oz
Functions
Specific Gravity, Parts Counting (NTEP for pill counting only), %, Density, Checkweighing (limit function), Animal Weighing, GLP Compliant Formulation, Statistics, Accumulation, Below Balance Weighing
Tare Range
To capacity by 100% subtraction
Power Source
Input: AC/DC Adapter, 100 - 240 VAC, 50 - 60 Hz, Output: 6 VDC, Dry Cell Batteries (4 x AA, Not Included)
Construction
Die cast aluminum base, ABS housing, Stainless Steel Platter, Anti-Static Glass Draft Shield
Die cast aluminum base, ABS housing, Stainless Steel Platter
Display
Large, easy to read 5/8" (16 mm) LCD display with backlight and icons
Pan Size
118 mm, 4.65" diameter
180 x 180 mm, 6.3" x 6.3"
Draft Shield Internal Dimensions (W x D x H)
5.9 x 5.9 x 7.87 inches
-
Overall Dimensions (W x D x H)
7 x 9 x 3 inches
7 x 9 x 3 inches
Operating Environment
41 o F to 95 o F / 5 o C to 35 o C< 2o C / hour
Connectivity
Output RS232 interface, USB Type B, with free RTS data collection software for Windows®
Net Weight
2.86 lb / 1.3 kg
Shipping Weight
6.5 lb / 2.94 kg
Options (Call/email)
Ethernet or Relay Contact (only one option per unit), Specific Gravity Measurement Kit, Underweighing Hook
Country of Origin
Japan
Features
Benefits
Easy calibration
Calibration is simple, ensuring that the balance will be calibrated often during use
Dedicated print button (output)
Easy data transfer to printer or computer
Large stainless steel pan
Allows for easy weighing of large objects
Spill ring
Protects against damage to electronic components
Adjustable bright, backlit LCD display
Easy to read in all lighting conditions including bright sunlight
Multiple weighing units
Allows flexibility of weighing
In use dust cover
Protects balance against spillage and contamination
4 Leveling feet for adjustment
The balance remains level for accurate results even on uneven working surfaces
Configurable RS232 interface and USB
Allows communication with peripheral data collection and printing instruments
Free Keys
Allows often used applications to be “one key” accessible
Dry Cell Battery Power
Allows for portability
