Mass comparator APP 4Y.KO series comprises two components. One of them holds the electronic module, and the other precise mechanical measuring system. Anti-draft chamber comes standard with the comparator.
RADWAGWAY APP 4Y.KO Manual Mass Comparator Anti-draft chamber comes standard with the comparator.

Have Questions?
oremail Us
Our Staff will be glad to help

Specifications Chart

RADWAGWAY APP 4Y.KO Manual Mass Comparator

RADWAG Self-Sentring Weighing Pan for APP
RADWAG Self-Sentring Weighing Pan for APP, add $1,379.70
RADWAG SA/APP/C Granite Anti-Vibration Table 700 x 450 x 225 mm Powder Coated Steel
RADWAG SA/APP/C Granite Anti-Vibration Table 700 x 450 x 225 mm Powder Coated Steel, add $996.80
RADWAG SA/APP/H Granite Anti-Vibration Table 700 x 450 x 225 mm Stainless Steel
RADWAG SA/APP/H Granite Anti-Vibration Table 700 x 450 x 225 mm Stainless Steel, add $1,286.40

Mass comparator APP 4Y.KO series comprises two components. One of them holds the electronic module, and the other precise mechanical measuring system.

High measuring accuracy is guaranteed by semi-automatic adjustment system with external mass standard. The weighing pan made of aluminium is covered with cork layer and features centering holders for the weights. The APP 4Y.KO series features an intuitive menu supporting a user in instrument operation.

For correct mass standards comparison process using comparator, it is required to use an anti-vibration granite table and an anti-draft chamber. Anti-draft chamber comes standard with the comparator. Anti-vibration table and its parameters sold separately

  • Effective and Excellent Measurement The APP 4Y.KO series stands for a class-leading manual mass comparator. These weighing instruments allow to compare 100 g - 50 kg weights of class E1 and lower.
  • Excellent Measurement Repeatability The APP 4Y.KO is comprised of two parts. One featuring an electromagnetic module, the other a precise mechanical measuring system. Weighing accuracy is assured thanks to a semi-automatic system of adjustment carried out using an external adjustment weight
  • Design and Functionality Weighing pan with a mechanical system for weights positioning facilitates precise loading of mass standards and eliminates eccentricity. This solution additionally allows for dissemination of reference mass to few weights.
  • Dedicated Software Specially-designed RMCS computer software enables comprehensive realisation of calibration procedures in laboratory. The system manages the whole calibration process, starting from the moment the order is placed, through procedure performance, to the moment of issuing the calibration certificate.
    Functions
  • Mass comparator
  • Ambient conditions measurement
  • Proximity sensors
  • Replaceable units
  • Multilingual menu

Weighing pan with mechanical system for weights positioning

Self-centring weighing pan

Model APP 10.4Y.KO APP 30.4Y.KO APP 64.4Y.KO
Price RADWAG APP 10.4Y.KO Class-leading manual mass comparator 10.2 kg x 0.1 mg
$14,780.48
RADWAG APP 30.4Y.KO Class-leading manual mass comparator 30.5 kg x 1 mg
$14,780.48
RADWAG APP 64.4Y.KO Class-leading manual mass comparator 64 kg x 10 mg
$16,099.60
Capacity x Readability 10.2 kg x 0.1 mg 30.5 kg x 1 mg 64 kg x 10 mg
Repeatability absolute * 0.8 mg (10 kg) 5 mg (20 kg) 30 mg (50 kg)
Repeatability nominal load * 0.5 mg (10 kg) 3 mg (20 kg) 18 mg (50 kg))
Repeatability low load * 0.35 mg (100 g) 3 mg (1 kg) 12 mg (2 kg)
Repeatability typical * 0.4 mg (10 kg) 3 mg (20 kg) 15 mg (20 kg)
Stabilization time 30 s 20 s 20 s
Adjustment External Calibration External Calibration External Calibration
Electric compensation range –100 g ÷ 200 g 100 g ÷ 30.5 kg 0 g ÷ 64 kg
Internal supplementary weights semi-automatic - -
External supplementary weights 300 g, 200 g - -
Eccentricity (for test weight) 2 d / 1 mm 2 d / 1 mm 2 d / 1 mm
OIML calibration range E1 5 kg ÷ 10 kg 20 kg -
OIML calibration range E2 1 kg ÷ 10 kg 5 kg ÷ 20 kg 50 kg
OIML calibration range F1 500 g ÷ 10 kg 2 kg ÷ 20 kg 20 kg ÷ 50 kg
OIML calibration range F2 100 g ÷ 10 kg 1 kg ÷ 20 kg 5 kg ÷ 50 kg
OIML calibration range M1 100 g ÷ 10 kg 1 kg ÷ 20 kg 2 kg ÷ 50 kg
OIML calibration range M2 100 g ÷ 10 kg 1 kg ÷ 20 kg 1 kg ÷ 50 kg
Display 5.7" color resistive touch screen
Keypad 8 keys
Ingress protection - indicator IP 43
Touch-free operation 2 programmable sensors
USB-A 2
Ethernet 10 / 100 Mbit
RS-232 2
Wi-Fi 802.11 b/g/n
IN/OUT 4 x IN, 4 x OUT
Power supply 110 ÷ 230 V AC / 50 ÷ 60 Hz
Operating temperature +15 ÷ +30 °C
Operating temperature change rate ±0.5 °C / 12 h (± 0.3 °C / 4 h) ±0.5 °C / 12 h ±3.5 °C / 12 h
Relative humidity variations ±3% / 4 h (30 ÷ 70)% ±10% / 4 h
Relative humidity*** 40 ÷ 60% ±5% / 4 h 40 ÷ 60%
Transport and storage temperature –20 ÷ +50 °C
Weighing pan dimensions ø 200 mm (ø 300 mm) ø 220 mm (ø 300 mm ø 300 mm (ø 400 mm
Self-centring weighing pan dimensions** ø 300 mm ø 300 mm ø 300 mm
Anti-draft chamber dimensions 660 x 680 x 450 mm 700 x 545 x 440 mm 700 x 545 x 440 mm
Mass comparator dimensions 455 x 385 x 315 mm 454 x 200 x 275 mm 520 x 205 x 400 mm
Dimensions of mass comparator with self-centring weighing pan** 455 x 385 x 315 mm
Indicator dimensions 206 x 140 x 71 mm
Mass comparator net weight 45 kg 23 kg 25 kg
Mass comparator gross weight 59 kg 37 kg 39 kg
Net weight of mass comparator with self-centring weighing pan** 47 kg 25 kg 25 kg
Anti-draft chamber net weight 18 kg 16 kg 16 kg
Gross weight of mass comparator with self-centring weighing pan** 49 kg 39 kg 39 kg
Anti-draft chamber gross weight 30 kg 28 kg 28 kg
Anti-draft chamber packaging dimensions 970 x 930 x 750 mm 960 x 830 x 730 mm 960 x 830 x 730 mm
Mass comparator packaging dimensions 1160 x 650 x 690 mm 1160 x 650 x 690 mm 1160 x 650 x 690 mm
Packaging dimensions of mass comparator with self-centring weighing pan** 1160 x 650 x 690 mm 1160 x 650 x 690 mm 1160 x 650 x 690 mm

* repeatability is expressed as a standard deviation determined for 6 ABBA cycles
** optional design
*** non-condensing conditions
Wi-Fi ® is a registered trademark of Wi-Fi Alliance.

Accessories - Call for more info

Weighing Tables
granite anti-vibration table
anti-vibration table for APP series mass comparators
Ambient Conditions
THB-S or THB-P sensor
Peripheral Devices
EEpson dot matrix printer
barcode scanner
WD-5/3Y LCD display (backlit)
Cables, Converters
RS-232 – P0108 computer cable
RS-232 – P0167 computer cable
RS-232 – P0151 Epson printer cable
Professional weighing
self-centring pan
Electrical Accessories
power supply with ZR–02 battery
Anti-Draft Chambers
anti-draft chamber for APP.3Y.KO mass comparator

Dedicated Software (not included) - Call for more info

RMCS System
  • performance of calibration procedures in a laboratory from the moment the order is placed, to the moment of issuing a calibration certificate
  • compatible with THB sensors enabling recording ambient conditions
  • export of report results to various files
  • archiving calibration protocols, orders, certificates and ambient conditions
R-LAB
  • collecting measurements
  • carrying out statistical analysis of measurements
  • customized graphs and reports
    Parameters Editor
  • remote change of parameters
  • remote on-line preview of the display
  • displaying current mass indication
  • software update
  • file loading, editing and saving parameters to a file
  • import and export of parameters
  • interfaces: RS232, Ethernet and Wireless Connection
  • quick and easy edition of balance parameters using computer ways of initializing the process of acquiring data from the weighing instrument and sending it to a computer
  • readout of characters transmitted via RS 232 to a computer
    RADWAG Remote Desktop
  • remote control of the mass comparator using computer, telephone or tablet
  • sending text messages
  • version for Windows 10 and Android systems
