Robust Design, Accurate Results
Special titration cell design minimizes ambient moisture interference for a low background drift value, ensuring accurate and repeatable measurements
One Click User Interface
With the intuitive One Click touchscreen interface, customize home screens to run your workflows quickly and easily with a single tap on the screen
Safe Chemical Handling
Reduce user contact with chemicals by automatically draining and refilling the titrator cell and preventing waste overflow with dedicated accessories
Diaphragm for Difficult Samples
The C10SD includes a cell diaphragm for highest accuracy, very low water samples (< 50 µg), nitro compounds or reducible unsaturated hydrocarbons
Secure Operation
Designate "Expert" and "Routine" user groups to allow full or limited access to titrator operations. A simple intuitive interface prevents differences or errors between users.
Manual Oven Option
Add a DO308 manual drying oven to fully release water from tricky samples. For single solid, viscous or poorly soluble samples like powders, granules, plastics, fibers, pastes, wool, tar, coal, and more
Flexible Data Management
Compact titrators offer multiple options for data handling. Export data in CSV, PDF or XML files via a memory stick or connect a printing device directly via the USB port
|
Model |
C10SD 30267115 |
C10SX 30267114 |
C20SD 30252661 |
C20SX 30252660 |
C30SD 30252663 |
C30SX 30252662 |
Selected
$9,662.70
|

$9,662.70
|

$12,052.80
|

$12,052.80
|

$19,159.00
|

$19,159.00
|
Max. number of methods |
5 |
150 |
LabX Software |
Not compatible |
Express and server (not included) |
Shortcuts per user |
4 |
12 |
User-Defined Calculations |
- |
- |
- |
- |
YES |
YES |
Application Type |
Karl Fischer (Coulometric) |
Karl Fischer (Coulometric) |
Karl Fischer (Coulometric) |
Karl Fischer (Coulometric) |
Karl Fischer (Coulometric) |
Karl Fischer (Coulometric) |
Automation Option(s) |
- |
- |
- |
- |
InMotion KF Oven |
InMotion KF Oven |
Barcode Reader Connection |
USB |
USB |
USB |
USB |
USB |
USB |
Compliance and Data Security |
Password protection,User management (fixed groups) |
Password protection,21 CFR Part 11, EudraLex, Volume 4, Annex 11 (with LabX software),User management (fixed groups) |
Connectivity and Software |
Network export,USB export |
LabX software,Network export,USB export |
LabX software,Network export,USB export |
Connection to printer |
YES |
YES |
YES |
YES |
YES |
YES |
Display |
Full-color 5.7 in VGA, touch screen |
Drying Oven Option |
DO308 (manual) |
Flexibility and Modularity |
Diaphragm (KF),Plug-and-play accessories,Sample weight transfer,One-click user interface,Pre-installed methods,User management |
Plug-and-play accessories,Sample weight transfer,One-click user interface,Pre-installed methods,User management |
Diaphragm (KF),Plug-and-play accessories,Sample weight transfer,PC software,One-click user interface,Solvent manager,User-defined calculations,Pre-installed methods,User management |
Plug-and-play accessories,Sample weight transfer,PC software,One-click user interface,Solvent manager,User-defined calculations,Pre-installed methods,User management |
Automation,Diaphragm (KF),Plug-and-play accessories,Sample weight transfer,PC software,One-click user interface,Solvent manager,User-defined calculations,Pre-installed methods,User management |
Automation,Plug-and-play accessories,Sample weight transfer,PC software,One-click user interface,Solvent manager,User-defined calculations,Pre-installed methods,User management |
Generator Cell |
With diaphragm |
Without diaphragm |
With diaphragm |
Without diaphragm |
With diaphragm |
Without diaphragm |
Karl Fischer titration |
YES |
YES |
YES |
YES |
YES |
YES |
Liquid Monitoring Option |
- |
- |
- |
- |
YES |
YES |
Measurement Range |
1 ppm – 5 % |
1 ppm – 5 % |
1 ppm – 5 % |
1 ppm – 5 % |
1 ppm – 5 % |
1 ppm – 5 % |
Measurement Type |
Karl Fischer (Coulometric) |
One Click® User Interface |
YES |
YES |
YES |
YES |
YES |
YES |
Samples per Analysis (Max.) |
120 |
120 |
120 |
120 |
120 |
120 |
Solvent Manager Option |
- |
- |
YES |
YES |
YES |
YES |
Task List (Max.) |
0 |
0 |
0 |
0 |
10 |
10 |
User Rights and Management |
Predefined Expert" and "Routine" roles" |
Languages |
Chinese, English, French, German, Italian, Korean, Polish, Portuguese, Russian, Spanish |
Customs tariff number |
9027898030 |
Model |
V10S 30267116 |
V20S 30252666 |
V30S 30252667 |

$9,765.00
|

$11,625.00
|

$18,331.00
|
Max. number of methods |
5 |
150 |
LabX Software |
Not compatible |
Express and server (not included) |
Shortcuts per user |
4 |
12 |
User-Defined Calculations |
- |
- |
YES |
Application Type |
Karl Fischer (Volumetric) |
Karl Fischer (Volumetric) |
Karl Fischer (Volumetric) |
Automation Option(s) |
- |
- |
InMotion KF Oven |
Barcode Reader Connection |
USB |
USB |
USB |
Compliance and Data Security |
Password protection,User management (fixed groups) |
Password protection,21 CFR Part 11, EudraLex, Volume 4, Annex 11 (with LabX software),User management (fixed groups) |
Connectivity and Software |
Network export,USB export |
LabX software,Network export,USB export |
LabX software,Network export,USB export |
Connection to printer |
YES |
YES |
YES |
Display |
Full-color 5.7 in VGA, touch screen |
Drying Oven Option |
DO308 (manual) |
Flexibility and Modularity |
Plug-and-play accessories,Sample weight transfer,SmartChemicals,One-click user interface,Pre-installed methods,User management |
Plug-and-play accessories,Sample weight transfer,SmartChemicals,PC software,Solvent manager,User-defined calculations,Pre-installed methods,User management |
Automation,Plug-and-play accessories,Sample weight transfer,SmartChemicals,PC software,One-click user interface,Solvent manager,User-defined calculations,Pre-installed methods,User management |
Liquid Monitoring Option |
- |
- |
YES |
Measurement Range |
100 ppm – 100 % |
100 ppm – 100 % |
100 ppm – 100 % |
Measurement Type |
Karl Fischer (Volumetric) |
One Click® User Interface |
YES |
YES |
YES |
Samples per Analysis (Max.) |
120 |
120 |
120 |
Solvent Manager Option |
- |
YES |
YES |
Plug & Play Features |
Burettes and Sensors |
Burettes and Sensors |
Burettes and Sensors |
Task List (Max.) |
0 |
0 |
10 |
User Rights and Management |
Predefined Expert" and "Routine" roles" |
Languages |
Chinese, English, French, German, Italian, Korean, Polish, Portuguese, Russian, Spanish |
Customs tariff number |
9027898030 |
Accessories |
Magnetic Stirrer Bar (51191159)
Barcode Reader Hand Scanner (21901297)
Bottle adapter (Merck) (23774)
Brown Glass Bottle, 1L (71296)
Cable USB (1.8 m A-B) for PC or printer (51191926)
Cable USB 412 (21901309)
Bottle adapter (Fisher) (23787)
Molecular Sieve 250 g (71478)
External power supply 100 - 240 VAC (51105795)
|
|
