Crane Scales: CAS Digital Industrial Scales

Four different heavy-duty series digital industrial crane scales: battery operated with AC adapters. Accurate and full featured with standard wireless remote controls, the CAS line of electronic digital industrial scales will have a model to meet your specifications.

CAS IE Series Economy Crane Scales

CAS NC1 Series Crane Scales

CAS Caston II Series Crane Scales

CAS Caston III Series Crane Scales

CAS Caston III BlueTooth Series Crane Scales

CAS IE Series Economy Crane Scales

Built Tough
Built to last with its sturdy aluminum die casting. The IE Series Crane Scale offers a compact portable design and will give you years of trouble free operation.

Hours of Use
A fully charged battery will offer up to 50 hours of use.

Easy to Read
Large 1.1 inch LCD or LED displays for easy reading from a long distance.

Features

100 to 2000 lb capacities
LCD or LED Display (1.1 inches/30mm)
Battery Operated
Low Battery and Overload Indicators
High Intensity Hook and Shackle
Heavy Duty Aluminum die cast case

Includes

AC Adapter
Rechargeable Battery
Wireless Remote Control

IE Series Model	IE-100C	IE-100E	IE-200C	IE-200E	IE-500C	IE-500E	IE-1000C	IE-1000E	IE-2000C	IE-2000E
Capacity	100 X 0.05 lbs		200 X 0.1 lbs		500 X 0.2 lbs		1000 X 0.5 lbs		2000 X 1 lbs
Price	$371.25	$371.25	$371.25	$371.25	$371.25	$371.25	$408.75	$408.75	$408.75	$408.75
Display Type	LCD	LED	LCD	LED	LCD	LED	LCD	LED	LCD	LED
Ext Resoloution	1/,2000 - 1/3,000
Max Tare	Full Tare
Display Digit	5 Digits
Function Key	Power, Zero, Tare, Hold
Operating Power	DC 9V/1500mA
Remote Ctrl Range	10M
Dimensions	8.9 (W) x 14.8 (H) x 5.1 (D) 225 (H) x 375 (H) x 130 (D)						8.7 (W) x 15.9 (H) x 5.1 (D)) 225 (W) x 405 (H) x 130 (D)
Product Weight	8.8 lbs / 4 kg						9.3 lbs / 4.2 kg

CAS NC-1 Series Scales

CAS NC-1 Electronic Digital Crane Scales are battery or AC operated with a weatherproof aluminum case.

Battery Operated with low battery indication
Standard AC adapter
Weatherproof cast aluminum case
On/Off, Zero, Tare and Kg/Lb functions
Easy to read LCD display with back light feature
Auto Span adjustment
Auto zero tracking
Wireless remote control
Rechargeable battery
Environmentally sealed to IP67 standards

Remote Control

NC-1 Model	NC-1-250	NC-1-500	NC-1-1000
Price	$596.25	$596.25	$637.50
Capacity	250 x 0.1 lb 125 kg x 50 g	500 x 0.2 lb 250 kg x 100 g	1000 x 0.5 lb 400 kg x 200 g
NTEP #	96-164	96-164	96-164
Maximum Tare	full tare
Display Type	LCD (1 inch)
Operating Power	DC 12V (1.5A)
Power Source	AC 120 V, 60 Hz
Display Designators	Zero, Tare, Battery
Power Consumption	0.25 W
Operating Temperature	-10°C ~ +40°C (14°F ~ 104°F)
Dimensions w x d x h	10.2" x 5.3" x 18.9" 260 x 134 x 480 mm

Caston II Digital Scales

Caston II digital crane scales come standard with a remote control, spare battery pack and battery charger.

Battery Operated with low battery indication
Rechargeable battery pack
Spare battery pack and charger included as standard
Remote control included as standard
On, Off, Zero and Tare functions
Easy to read 1.2" LED Display
Auto span adjustment
Auto Zero Tracking

Display & Keyboard
Display

Battery Pack Installation
Caston Battery pack

Caston II Model	0.5-THB	1-THB	2-THB	5-THB
Price	$1068.75	$1068.75	$1068.75	$1196.25
Capacity	1000 x 0.5 lb 500 kg x 0.2 kg	2000 x 1 lb 1000 x 0.5 kg	5000 x 1 lb 2000 x 0.5 kg	10,000 x 2 lb 5000 x 1 kg
Maximum Tare	full tare
Display Type	LCD (1.2 inch)
Operating Power	DC 6V
Power Source	AC 120 V, 60 Hz
Display Designators	Zero, Tare, Battery
Power Consumption	1 W
Operating Temperature	-10°C ~ +40°C (14°F ~ 104°F)
Product Weight	37.5 lb (17 kg)

Caston III Digital Scales

CAS Caston III Digital Crane Scales come standard with rechargable battery pack, spare battery, charger and remote control.

Battery Operated with low battery indication
Rechargeable battery pack
Spare battery pack and charger included as standard
Remote control included as standard
On, Off, Zero, Tare and Hold (manual or automatic) functions
Easy to read 1.5" LED Display
Auto span adjustment
Auto Zero Tracking
Environmentally sealed to IP 67 standards

Model	5-THD	10-THD	15-THD	20-THD	30-THD	50-THD
Price	$1796.25	$2695.25	$3296.25	$3746.25	$7421.25	$12,596.25
Capacity	10000 x 5 lb 5000 kg x 2 kg	20000 x 10 lb 10000 x 5 kg	30000 x 10 lb 15000 x 5 kg	40000 x 20 lb 20000 X 10 kg	60000 x 20 lb 30000 X 10 kg	100,000 x 50 lb 50,000 x 20 kg
Shipping Wt.	98 lbs	153 lbs	158 lbs	240 lbs	710 lbs	1050 lbs
Maximum Tare	Full Tare
Accuracy	Plus or minus 0.1% of applied load
Overload	Safety: 150% of rated capacity Ultimate: 300% of rated capacity
Housing	Alodined cast aluminum Double O-ring gasket NEMA 4 IP 65
Hook, Eye, Shackles	Crosby or equivalent
Display Type	LED / 6 Digit (1.5 inch)
Calibration	Manual
Operating Power	DC 12V
Operating Time	14 - 24 hours
Power Source	AC 120V, 50/60 Hz
Display Designators	Zero, Tare, Hold, Batt
Power Consumption	1.2W
Operating Temp	-10�C ~ 40�C / 14�F ~ 104�F

Caston III BlueTooth Digital Scales

CAS Caston III BlueTooth digital crane scale

Battery Operated w/Low Battery Indicator
Rechargeable Battery Pack
Spare Battery Pack and Charger Included
Easy to Read 1.5� Display
On, Off, Zero, Tare, and Hold (Manual or Automatic) Functions
Auto Span Adjustment
Auto Zero Tracking
Includes - Wireless Remote for Caston III Models - TW-100 Bluetooth Remote Control for Caston III BT Model - Remote Base includes RS-232C - Cradle included with 60K & 100K Models

10K, 20K, 30K, 40K, 60K, & 100K Capacities
Bluetooth Wireless Remote Control (TW100)
Battery Operated (Rechargeable)
Spare Battery Pack & Charger Included
Easy to Read 1.5" LED Display
On, Off, Zero, Tare, & Hold Buttons
Auto Span Adjustment
Auto Zero Tracking
Bluetooth Oprating Range over 350ft

Specs

Model	5-THD-BT	10-THD-BT	15-THD-BT	20-THD-BT	30-THD-BT	50-THD-BT
Price	$3671.25	$5246.25	$5771.25	$5996.25	$8171.25	$13121.25
Capacity	10000 x 2 lb 5000 kg x 1 kg	20000 x 5 lb 10000 x 2 kg	30000 x 10 lb 15000 x 5 kg	40000 x 20 lb 20000 X 10 kg	60000 x 20 lb 30000 X 10 kg	100,000 x 50 lb 50,000 x 20 kg
Shipping Wt.	98 lbs	153 lbs	158 lbs	240 lbs	710 lbs	1050 lbs
Maximum Tare	Full Tare
Accuracy	Plus or minus 0.1% of applied load
Overload	Safety: 150% of rated capacity Ultimate: 300% of rated capacity
Housing	Alodined cast aluminum Double O-ring gasket NEMA 4 IP 65
Hook, Eye, Shackles	Crosby or equivalent
Display Type	LED / 6 Digit (1.5 inch)
Frequency (BT)	2.4 Ghz
Remote Distance (BT)	Up to 350 ft / 106.7 m
Channels (BT)	Up to 79 separate channels
Calibration	Manual
Operating Power	DC 12V
Operating Time	14 - 24 hours
Power Source	AC 120V, 50/60 Hz
Display Designators	Zero, Tare, Hold, Batt
Power Consumption	1.2W
Operating Temp	-10�C ~ 40�C / 14�F ~ 104�F
