MSI 178006 6in LASERLIGHT2 RF Six-Digit Scoreboard with ScaleCore RF Kit and Tilt Mounting Bracket |
|
| Prominently display weight, numeric data and messages with the
LaserLight2 remote display. A super-bright LED display with non-glare
lens provides sharp seven-segment, six-digit characters that are easy to
read. more ... |
|
Scales >
Crane Scales & Dynamometers >
Accessories
|
|
Have Questions?
Our Staff will be glad to help |
|
|
|
|
|
|
|
|
|
Features
Prominently display weight, numeric data and messages with the
LaserLight2 remote display. A super-bright LED display with non-glare
lens provides sharp seven-segment, six-digit characters that are easy to
read. Never lose visibility in dark conditions or experience wash-out in
direct sunlight. Simply power up a LaserLight2 remote display in your
application and the benefits are clearly visible.
A redesigned enclosure provides easy access to internal
components. The front panel swings open for
convenient setup and service, yet
is securely held in place.
The weather-tight, IP66
rated enclosure provides
superior protection for
worry-free daily use. The
external keypad makes
navigating configuration
options safe and easy
with up, down, left and
right arrow keys as well as Enter, Setup, Mode, Set and Learn buttons.
Available in four-inch or six-inch character sizes, LaserLight2 remote displays
include annunciators for gross, net, pounds, and kilograms. For added
convenience, time and date is also included.
Standard Features
- Six high-intensity red digits (double-row discrete LED)
- Auto Learn mode of communication protocol
- Hold displayed weight (demand input)
- Software selectable standstill mode for no updates while in motion
- Mirror (reverse image) feature, auto mode
- Durable weather-tight IP66 enclosure
- Adjustable daylight/night intensity
- Non-glare contrast filtered lens
- RS-232, 20 mA, and RS-485 communications
- Auto sensing 115/230 VAC power supply
- PEMs locations accomdate flange or VESA mounting brackets
- Polyethylene breather vent inhibits internal moisture buildup
- Red, green and arrow lights in Stop/Go model
| Display |
6-digit, 7-segment discrete oval precision optical
performance red LED lamps
Contrast enhanced optical filtering lens
1- or 2- place decimal or comma indication
4 annunciators for GR, NT, lb, kg
4-inch red, green ball/arrow in Stop/Go model |
| Maximum
Viewing Distance |
4-inch: 200 ft (60 m)
6-inch: 300 ft (100 m) |
| Input Interface |
RS-232, RS-485, 20 mA current loop
(active or passive, switch selectable) |
| Input Data Format |
Baud Rate: 1200, 2400, 4800, 9600 and 19,200
self-learning or software selectable |
| Character Format |
7 or 8 data bits; even, odd, or no parity; 1 or 2 stop bits,
self-learning or software selectable |
| Update |
Continuous or out-of-motion only; software selectable |
| Power Consumption |
4-inch: 21 watt
6-inch: 27 watt |
| Time |
Software enable/disable, 12- or 24-hour format |
| Date |
Software enable/disable, US or ISO format |
| Rating/Material |
IP66 Weather tight, mild steel, black powder coated |
| Dimensions |
4-inch (L x H): 22.28 in x 9.8 in
6-inch (L x H): 30.63 in x 12.77 in
Stop/Go (L x H): 30.63 in x 12.77 in
(flanges add 3.16 inches in width) |
| Weight |
4-inch: 20 lb (9 kg)
6-inch and Stop/Go: 25 lb (11 kg) |
| Operating
Temperature Range |
-40°F to 120°F (-40°C to 49°C) |
| Warranty |
Two-year limited warranty |
|
2 Year Manufacture Warranty
|
