The PT-20 Axle Weigher CPU is Designed to Interface with Intercomp’s Complete Line of Wheel Load and Axle Scales.  This central processing unit can be connected to multiple scales for vehicle and truck weighing applications.

The PT-20 is another Intercomp product developed to meet the increasing demand for mobile and highly efficient operations within the transportation industry. No longer does the operator need to tally individual wheel weights and manually compute total vehicle weight. This portable, battery operated unit automatically executes the entire task.

The PT-20’s self-prompting software simultaneously displays up to five axle weights and total weight on a large 4-line by 20-character LCD screen.  Obtaining a hard-copy of the information is simple via the on-board printer which prints the location, date and time for each vehicle that has been weighed.

The PT-20 is designed to accommodate Intercomp’s PT300, PT300DW and LP600 series wheel load scales, along with Intercomp’s AX900 series axle scales. In addition, its high tech digital design enables communication with any wheel load or axle scale, anywhere, at any time. It will even interface with a notebook computer to directly transmit all stored data.

The PT-20 includes additional features such as screen contrast adjustability, a backlight for night usage, AC or DC power source and simultaneous zeroing of all platforms. These and several other useful features are available via the 7-layer membrane keypad. The weatherproof case enables use in virtually any environment and the central processor, cables, power supply and manual are packed for easy transport to weigh at the most remote locations.  Most importantly, the PT-20 Axle Weigher CPU is designed and field-proven by Intercomp Company, the leading authority in portable vehicle and truck weighing.

Designed to work with Intercomp's PT300 Wheel Load Scales, LP600 Low-Profile Wheel Load Scales, AX900 Axle Load Scales, and MS450 Mining Scale Systems.

Please call for more detailed information.

Here is a top quality impact printer that replaces bulky, expensive printers where 80-column capacity is unnecessary.  It is available in RS-232C serial and 20mA current loop interfaces.

Many Uses

Only the imagination limits the number of profitable uses for this small and versatile printer.  They include: inventory control in combination with bar code scanners, hard-copy credit card verification, documentation of data received from automotive diagnostic equipment, remote message printing, peripheral equipment for scale applications, documentation of medical and dental procedures, logging data from testing procedures in laboratories and manufacturing.
Uses plain paper Printer uses inexpensive, easily obtained 2 1/4" adding machine paper
that doesn’t gum up the printhead as thermal and electrosensitive coated paper can. Printouts are sharp and don’t fade.  Ribbon cartridges are easily replaceable and are available in black or purple.

GENERAL SPECIFICATIONS

• Interface
  • Serial: BAUD rate - 1200.
  • Voltage levels - RS-232C: -10 Volts to +5 Volts
• Line Buffering
  • Full column width character buffering is provided for line at a time printing. When text exceeds line length, it automatically wraps around.
• Print method - Impact dot matrix
• Character matrix
  • 6 x 8 dot matrix
• Character Spacing
  • 24 column: 12.8 characters/inch
• Line feed spacing
  • 7.6 lines per inch..character mode
  • 9.1 lines per inch..graphic mode
• Print speed - 42 lines per minute (24 column)
• Paper - Table top: 2.25"W x 2.75"D; 0.44" I.D.
• Power - 1.5 Watts (idle), 10 Watts (while printing)
• AC voltage
  • 9 VAC -120 VAC stepdown converter included
  • 220 Volt optional
• DC voltage
  • Optional 9-12 VDC
  • 150mA idle, 850mA typical, 1.5A peak
• External dimensions
  • 4"W x 4.5"L x 2"H
• Operating temperature
  • 5°C - 40°C, 41°F - 104°F
• Print head life
  • 500K lines mean character before failure
• Ribbon life
  • Black - 20,000 characters
  • Purple - 250,000 characters
• P. Paper
  • Large roll - 12,500 lines
  • Small roll - 3,000 lines

Specifications subject to change without notice.

Works with CW500 Cargo Scale Systems, PT300 Wheel Load Scale Systems, LP600 Low-Profile Wheel Load Scale Systems, and AX900 Axle Load Scale Systems.
