Intercomp PT300DW 100110 Digital Wheel Load Scale System (Double Wide), 4-10K-40000 x 5 lb Intercomp Company, Inc. is the world's largest manufacturer of portable weighing solutions

The PT300DW scales are designed to maximize legal payloads with concern for violations and reduction of maintenance due to overload stress on equipment.

The PT300DW is a sturdy, all aluminum, fully electronic, self-contained wheel load scale that is capable of weighing loads up to 20,000lbs/10,000kg with an accuracy of +/-1%.

more ...
Scales > Industrial Scales > Digital Platform Scales
Intercomp PT300DW 100110 Digital Wheel Load Scale System (Double Wide), 4-10K-40000 x 5 lb

Price: $9,540.00


In Stock - Ships within 24 hours

Optional Accessories
Intercomp Part 330010 Battery Pack for CW250& PT300 & Lp600 , $42.00
Intercomp Part 100051 4 Scale Carrying Case for PT300DW (Custom Order) , $1,152.00
Intercomp Part 101064 4 Scale PT/LP Cigarette Adapter Charger , $425.70
Intercomp Part 100856 Charger, External, 120/220 Volt, 6x6 NiCad Battery Packs/NiMH for PT300 , $265.50
Intercomp Part 101113 4 Scale - Totalizing to Computer, Continuous Output, 9 Pin D-sub for PT300 , $382.50
Intercomp Part 101112 4 Scale - Totalizing to Computer, Demand Output, 9 Pin D-sub for PT300 , $382.50
Intercomp Part 100540 PT20CPU Battery Operated Portable Computer for PT300 , $5,216.00
Intercomp Part 101119 Cable, 4PT Totalizing to P-DP Printer for PT300 , $382.50
Intercomp Part 100088 Dummy Pad (Cast Aluminum Replica) for PT300 , $345.00
Intercomp Part 100489 Interconnecting Cable and Connectors for 4 Scales (15, 25, 15 ft spacing) for PT300 , $306.00
Intercomp Part 100090 P-DP Battery operated tape printer , $716.00
Intercomp Part 140656 USB Wireless Node - ZigBee for Notebook fits CW250, PW800 & PT300 , $445.50
Intercomp Part 140626 PDA with 868 MHz & Vehicle Weigh Software , $2,246.00
Intercomp Part 340105 Thermal Printer, Roll, Battery or AC Operation for Intercomp CW250 (Need 101165 cable) , $595.00
Intercomp Part 100072 Ramp for PT300DW , $131.00

View Features

SKU: 100110
Other Intercomp PT300DW Wheel Load Scale Systems with 4 Scales

PT300DW 100111
Digital Wheel Load Scale System (Double Wide)
4-5K-20000 x 5 lb

Price: $9,000.00

PT300DW 100106
Digital Wheel Load Scale System (Double Wide)
4-20K-80000 x 100 lb

Price: $9,000.00

PT300DW 100107
Digital Wheel Load Scale System (Double Wide)
4-20K-80000 x 50 lb

Price: $9,000.00

PT300DW 100108
Digital Wheel Load Scale System (Double Wide)
4-20K-80000 x 20 lb

Price: $9,000.00

PT300DW 100109
Digital Wheel Load Scale System (Double Wide)
4-20K-80000 x 10 lb

Price: $9,540.00

PT300DW 100110
Digital Wheel Load Scale System (Double Wide)
4-10K-40000 x 5 lb

Price: $9,540.00

Features

The PT300DW scales are designed to maximize legal payloads with concern for violations and reduction of maintenance due to overload stress on equipment.

The PT300DW is a sturdy, all aluminum, fully electronic, self-contained wheel load scale that is capable of weighing loads up to 20,000lbs/10,000kg with an accuracy of +/-1%.

The scales are fully battery operated and only require infrequent recharging through 12V, 110V, or 220V power sources.

The display can be lit for night use and it is possible to sequentially couple and number of PT300DW scales in the series for the purpose of obtaining a total vehicle weight through the total button as well as link the scales to a computer, indicator, or Intercomp's PT20 Universal CPU.

Available in wired and wireless configurations to best meet your needs.

SYSTEM INCLUDES:

  1. Two Scales with 20mA Output
  2. Interconnecting Cable
  3. Charging Cable
  4. Carrying Case
  5. PT300DW (Double Wide) Wheel Load Scales Four Scales
    Self Contained Digital Wheel Load Scale System for Portable Weighing.
    Includes: Four Scales with 20mA Output, Interconnecting Cable, Charging Cable and Carrying Case. Specify the appropriate battery charger for your application.
    Model Description Capacity/Graduation Weight
    100106 Digital Wheel Load Scale System (Double Wide) 4-20K-80,000 x 100 lb/40,000 x 50 kg 310 lb
    100107 Digital Wheel Load Scale System (Double Wide) 4-20K-80,000 x 50 lb/40,000 x 20 kg 310 lb
    100108 Digital Wheel Load Scale System (Double Wide) 4-20K-80,000 x 20 lb/40,000 x 10 kg 310 lb
    100109 Digital Wheel Load Scale System (Double Wide) 4-20K-80,000 x 10 lb/40,000 x 5 kg 310 lb
    100110 Digital Wheel Load Scale System (Double Wide) 4-10K-40,000 x 5 lb/20,000 x 2 kg 310 lb
    100111 Digital Wheel Load Scale System (Double Wide) 4-5K-20,000 x 5 lb/10,000 x 2 kg 310 lb
    100106-RF Wireless Wheel Load Scale System (Double Wide) with Handheld Computer 4-20K-80,000 x 100 lb/40,000 x 50 kg 310 lb
    100107-RF Wireless Wheel Load Scale System (Double Wide) with Handheld Computer 4-20K-80,000 x 50 lb/40,000 x 20 kg 310 lb
    100108-RF Wireless Wheel Load Scale System (Double Wide) with Handheld Computer 4-20K-80,000 x 20 lb/40,000 x 10 kg 310 lb
    100109-RF Wireless Wheel Load Scale System (Double Wide) with Handheld Computer 4-20K-80,000 x 10 lb/40,000 x 5 kg 310 lb
    100110-RF Wireless Wheel Load Scale System (Double Wide) with Handheld Computer 4-10K-40,000 x 5 lb/20,000 x 2 kg 310 lb
    100111-RF Wireless Wheel Load Scale System (Double Wide) with Handheld Computer 4-5K-20,000 x 5 lb/10,000 x 2 kg 310 lb


Optional Accessories
Intercomp Part 330010 Battery Pack for CW250& PT300 & Lp600

$42.00



Intercomp Part 330010 Battery Pack for CW250& PT300&Lp600
Intercomp Part 100051 4 Scale Carrying Case for PT300DW (Custom Order)

$1,152.00



Intercomp Part 100051 4 Scale Carrying Case for PT300DW (Custom Order)
Intercomp Part 101064 4 Scale PT/LP Cigarette Adapter Charger

$425.70



Intercomp Part 101064 4 Scale PT/LP Cigarette Adapter Charger
Intercomp Part 100856 Charger, External, 120/220 Volt, 6x6 NiCad Battery Packs/NiMH for PT300

$265.50



Intercomp Part 100856 Charger, External, 120/220 Volt, 6x6 NiCad Battery Packs/NiMH for PT300
Intercomp Part 101113 4 Scale - Totalizing to Computer, Continuous Output, 9 Pin D-sub for PT300

$382.50



Intercomp Part 101113 4 Scale - Totalizing to Computer, Continuous Output, 9 Pin D-sub for PT300
Intercomp Part 101112 4 Scale - Totalizing to Computer, Demand Output, 9 Pin D-sub for PT300

$382.50



Intercomp Part 101112 4 Scale - Totalizing to Computer, Demand Output, 9 Pin D-sub for PT300
Intercomp Part 100540 PT20CPU Battery Operated Portable Computer for PT300

$5,216.00



The PT-20 Axle Weigher CPU is Designed to Interface with Intercomp’s Complete Line of Wheel Load and Axle Scales.  This central processing unit can be connected to multiple scales for vehicle and truck weighing applications.

The PT-20 is another Intercomp product developed to meet the increasing demand for mobile and highly efficient operations within the transportation industry. No longer does the operator need to tally individual wheel weights and manually compute total vehicle weight. This portable, battery operated unit automatically executes the entire task.

The PT-20’s self-prompting software simultaneously displays up to five axle weights and total weight on a large 4-line by 20-character LCD screen.  Obtaining a hard-copy of the information is simple via the on-board printer which prints the location, date and time for each vehicle that has been weighed.

The PT-20 is designed to accommodate Intercomp’s PT300, PT300DW and LP600 series wheel load scales, along with Intercomp’s AX900 series axle scales. In addition, its high tech digital design enables communication with any wheel load or axle scale, anywhere, at any time. It will even interface with a notebook computer to directly transmit all stored data.

The PT-20 includes additional features such as screen contrast adjustability, a backlight for night usage, AC or DC power source and simultaneous zeroing of all platforms. These and several other useful features are available via the 7-layer membrane keypad. The weatherproof case enables use in virtually any environment and the central processor, cables, power supply and manual are packed for easy transport to weigh at the most remote locations.  Most importantly, the PT-20 Axle Weigher CPU is designed and field-proven by Intercomp Company, the leading authority in portable vehicle and truck weighing.

Designed to work with Intercomp's PT300 Wheel Load Scales, LP600 Low-Profile Wheel Load Scales, AX900 Axle Load Scales, and MS450 Mining Scale Systems.

Intercomp Part 101119 Cable, 4PT Totalizing to P-DP Printer for PT300

$382.50



Intercomp Part 101119 Cable, 4PT Totalizing to P-DP Printer for PT300
Intercomp Part 100088 Dummy Pad (Cast Aluminum Replica) for PT300

$345.00



Intercomp Part 100088 Dummy Pad (Cast Aluminum Replica) for PT300
Intercomp Part 100489 Interconnecting Cable and Connectors for 4 Scales (15, 25, 15 ft spacing) for PT300

$306.00



Intercomp Part 100489 Interconnecting Cable and Connectors for 4 Scales (15, 25, 15 ft spacing) for PT300
Intercomp Part 100090 P-DP Battery operated tape printer

$716.00



P-DP
A Little Printer for Big Jobs

Here is a top quality impact printer that replaces bulky, expensive printers where 80-column capacity is unnecessary.  It is available in RS-232C serial and 20mA current loop interfaces.

Many Uses

Only the imagination limits the number of profitable uses for this small and versatile printer.  They include: inventory control in combination with bar code scanners, hard-copy credit card verification, documentation of data received from automotive diagnostic equipment, remote message printing, peripheral equipment for scale applications, documentation of medical and dental procedures, logging data from testing procedures in laboratories and manufacturing.
Uses plain paper Printer uses inexpensive, easily obtained 2 1/4" adding machine paper
that doesn’t gum up the printhead as thermal and electrosensitive coated paper can. Printouts are sharp and don’t fade.  Ribbon cartridges are easily replaceable and are available in black or purple.

GENERAL SPECIFICATIONS

  • Interface
    • Serial: BAUD rate - 1200.
    • Voltage levels - RS-232C: -10 Volts to +5 Volts
  • Line Buffering
    • Full column width character buffering is provided for line at a time printing. When text exceeds line length, it automatically wraps around.
  • Print method - Impact dot matrix
  • Character matrix
    • 6 x 8 dot matrix
  • Character Spacing
    • 24 column: 12.8 characters/inch
  • Line feed spacing
    • 7.6 lines per inch..character mode
    • 9.1 lines per inch..graphic mode
  • Print speed - 42 lines per minute (24 column)
  • Paper - Table top: 2.25"W x 2.75"D; 0.44" I.D.
  • Power - 1.5 Watts (idle), 10 Watts (while printing)
  • AC voltage
    • 9 VAC -120 VAC stepdown converter included
    • 220 Volt optional
  • DC voltage
    • Optional 9-12 VDC
    • 150mA idle, 850mA typical, 1.5A peak
  • External dimensions
    • 4"W x 4.5"L x 2"H
  • Operating temperature
    • 5°C - 40°C, 41°F - 104°F
  • Print head life
    • 500K lines mean character before failure
  • Ribbon life
    • Black - 20,000 characters
    • Purple - 250,000 characters
  • P. Paper
    • Large roll - 12,500 lines
    • Small roll - 3,000 lines

Specifications subject to change without notice.

Works with CW500 Cargo Scale Systems, PT300 Wheel Load Scale Systems, LP600 Low-Profile Wheel Load Scale Systems, and AX900 Axle Load Scale Systems.

Intercomp Part 140656 USB Wireless Node - ZigBee for Notebook fits CW250, PW800 & PT300

$445.50



Intercomp Part 140656 USB Wireless Node - ZigBee for Notebook fits CW250, PW800 & PT300
Intercomp Part 140626 PDA with 868 MHz & Vehicle Weigh Software

$2,246.00



Intercomp Part 140626 PDA with 868 MHz & Vehicle Weigh Software
Intercomp Part 340105 Thermal Printer, Roll, Battery or AC Operation for Intercomp CW250 (Need 101165 cable)

$595.00



This compact, fully featured, portable thermal printer is the perfect printer for your weighing system application.

The small, lightweight design ensures this printer can be used on the go, and it's high speed, low noise mechanism is perfect for any environment.

This printer features a long life print head with high reliability, easy paper handling, a large capacity Lithium-ion rechargeable battery, and your choice of paper diameters up to 40mm.

GENERAL SPECIFICATIONS

  • Interface
    • Serial Interface
  • Printing System
    • Direct Thermal Printing
  • Printing Speed
    • 50mm/Sec
  • Character matrix
    • ASCII Code, Alphanumeric Characters, International Characters, Windows Code Page
  • Characters Per Line
    • 32 - 42 Characters per Line, Two Font Size Choices
  • Paper Width
    • 58 +/-0.5mm
  • Recommended Paper
    • TF50-KS-E2D (Nippon Paper)
  • External dimensions
    • 4.5"x4"x2.5"/116W x 104L x 63Hmm
    • 5°C - 40°C, 41°F - 104°F
  • Weight
    • Less Than 1lb

Printer Includes:

  1. Printer
  2. 1 Sample Roll of Paper
  3. AC Adapter
  4. Battery
  5. Serial Cable

Fully compatable with Intercomp's CS750 Crane Scale, CS1500 Crane Scale, CS3000 Crane Scales, CS5000 Crane Scales, TL6000 Tension Link Scales, CW250 Cargo Scales, TB830 Twin Beam Scales, US840 U-Beam Scales, PT300 Wheel Load Scales, LP600 Low-Profile Wheel Load Scales, GP1000 Indicator, GP1200 Indicator, GP2000 Indicator, GP2000EM Indicator and the MS450 Mining Scale Systems.

Intercomp Part 100072 Ramp for PT300DW

$131.00



Intercomp Part 100072 Ramp for PT300DW
