Rice Lake Dimension Scales
iDimension’s multiple patented, innovative sensing technology and 3D imaging work together to optimize time and throughput. Parcels are dimensioned more accurately and faster than manual measurements. In an industry leading 0.2 seconds, dimensions are calculated within 0.2 inches of accuracy.

100 Series

200 Series

300 Series (with optnion stand)
Rice Lake Dimension Scale

Model

Optional

Rice Lake 166111 iDimension 300 3D Imaging System Stand, add $1,495.00

Mettler Toledo® BC-60U (BCA-222-60U-B101-110) Parcel Legal for Trade Shipping Scale 150 x 0.05 lb, add $515.00

Specifications Chart

call now

iDimension’s multiple patented, innovative sensing technology and 3D imaging work together to optimize time and throughput. Parcels are dimensioned more accurately and faster than manual measurements. In an industry leading 0.2 seconds, dimensions are calculated within 0.2 inches of accuracy.

Rice Lake iDimension 200 NTEP 3D Imaging System & Mettler Toledo® PS60 Shipping Scale, 150 lb x 0.05 lb
Rice Lake iDimension 200 NTEP
3D Imaging System & Mettler Toledo® PS60 Shipping Scale,
150 lb x 0.05 lb

Price: $18,020.00
In Stock
btn buy

iDimension is an American-made product supported by a worldwide network of service providers and is Legal for Trade. (NTEP CC-15-023P). The standard operator interface provides functionality from any Rice Lake iDimension 200 are made in the USA PC or tablet connected to the network. iDimension provides L x W x H and an image of the scanned item. Integrating an existing scale with iDimension attaches weight to the displayed data.

STANDARD FEATURES
  • Calculates dimensions in less than 0.2 seconds
  • Instantly captures dimensions, weight, barcodes, OCR text and image of static items
  • Dimensions packages (NTEP), flats and irregular objects
  • Converts irregular objects like cylinders, spheres, tubes, polybags and uneven objects to accurate cubed dimensions
  • No moving parts
  • Requires virtually no alignment or special handling while placing the object under the work area
  • Automatic or Manual operating modes
  • Manual Mode: Initiate dimension of item via barcode scan or software function key
  • Automatic Mode: Initiate dimension via detection of object in work area
  • Interfaces with most shipping scales and select Rice Lake indicators
  • Quick assembly: includes necessary tools
  • Easy to set up and calibrate: Includes calibration object and embedded web service interface via a fixed IP or DHCP
Legal For Trade
Series
iDimension 100 iDimension 200 iDimension 300
Head Unit Head Unit & Stand
Rice Lake iDimension 200 NTEP<br> 3D Imaging System & Mettler Toledo® PS60 Shipping Scale,<br> 150 lb x 0.05 lb
$6,495.00
buy now
Rice Lake iDimension 200 NTEP<br> 3D Imaging System & Mettler Toledo® PS60 Shipping Scale,<br> 150 lb x 0.05 lb
$17,495.00
buy now
Rice Lake iDimension 200 NTEP<br> 3D Imaging System & Mettler Toledo® PS60 Shipping Scale,<br> 150 lb x 0.05 lb
$16,995.00
buy now
Rice Lake iDimension 200 NTEP<br> 3D Imaging System & Mettler Toledo® PS60 Shipping Scale,<br> 150 lb x 0.05 lb
$18,490.00
buy now
Physical Dimension Length: 25"
Width: 22"
Height: 63.8"
Weight: 28.5lbs
Length: 25.5"
Width: 14"
Height: 67"
Weight: 28lbs
- -
Power Requirements Single power source 110-240V external power supply Single power source 110-240V external power supply Single power source 110-240V power cord and cable with 3 conductor PC, power connector socket
Operating Temperature 41°F to 104°F
(5°C to 40°C)
41°F to 104°F
(5°C to 40°C)
41°F to 104°F
(5°C to 40°C)
Humidity Non-condensing Non-condensing Non-condensing
Mechanical Environment Class M1 M1 M1
I/O ports (USB type A port (interface to scale)
10/100/100BASE-T Ethernet port (interface to PC)
(3)USB type A ports
(1)10/100/100BASE-T Ethernet port
(3)USB type A ports
(1)10/100/100BASE-T Ethernet port
Electromagnetic Class E1 E1 E1
Bar Codes Supported -
    EAN13
    UPCA & 2/5 digit extensions
    Code 128 and UCC/EAN-128 encoding
    Code 39
    Code 93
    EAN 8
    UPC-3
    UPC 2/5 digit extensions
    Interleaved 2 of 5
    Codabar
    Patch Codes
    PDF 417
    Datamatrix
    QR Code
    EAN13
    UPCA & 2/5 digit extensions
    Code 128 and UCC/EAN-128 encoding
    Code 39
    Code 93
    EAN 8
    UPC-3
    UPC 2/5 digit extensions
    Interleaved 2 of 5
    Codabar
    Patch Codes
    PDF 417
    Datamatrix
    QR Code
Package Contents iDimension 100 assembly tools, calibration object, USB display and US power cord iDimension 200 assembly tools and calibration object 15602 - iDimension 300 head assembly with mounting bolts & calibration object
166111 - Stand
Adjustable floor mounted stand and hardware
Warranty One-year limited warranty One-year limited warranty One-year limited warranty
Approval NTEP, CE, FCC, OIML - pending NTEP CC 15-023P NTEP CC 15-023P
NTEP Measurement Ranges - Cube
iDimension 100 iDimension 200 iDimension 300
LENGTH MIN (IN) 5.6 5.6 7
LENGTH MAX (IN) 48 48 48
LENGTH DIVISION (IN) 0.2 0.2 0.2
WIDTH MIN (IN) 5.6 5.6 7
WIDTH MAX (IN) 28 28 32
WIDTH DIVISION (IN) 0.2 0.2 0.2
HEIGHT MIN (IN) 2.4 2.4 2.4
HEIGHT MAX (IN) 28 28 28
HEIGHT DIVISION (IN) 0.2 0.2 0.2
NTEP Measurement Ranges - Irregular
iDimension 100 iDimension 200 iDimension 300
LENGTH MIN (IN) 6 6 7
LENGTH MAX (IN) 48 48 58
LENGTH DIVISION (IN) 0.5 0.5 0.5
WIDTH MIN (IN) 6 6 7
WIDTH MAX (IN) 28 28 32
WIDTH DIVISION (IN) 0.5 0.5 0.5
HEIGHT MIN (IN) 6 6 6
HEIGHT MAX (IN) 28 28 32
HEIGHT DIVISION (IN) 0.5 0.5 0.5

iDimension 100

iDimension 100 is the future of dimensioning. Designed as an economical solution for low- and high-volume shipping applications, iDimension 100 dimensions packages, flats and irregular shapes in sub-second speeds.iDimension 100 is equipped with the same durable dimensioning functionality and operating versatility as the iDimension Series, yet streamlined with an industry-leading compact footprint.

Like its predecessors, iDimension 100 includes the same DHCP IP address web service and free API for users to interface with the system using a simple HTTP request and XML parsing method. Ideal for industrial and countertop settings, iDimension 100 can be used in retail workstations, offices, shipping and manufacturing environment.

Standard Features
  • Dimensions parcels in less than 2/10th of a second at 0.2 in NTEP Certified accuracy
  • Includes USB operator display (no PC interface required) for:
  • Manual entry of dimensions into 3rd party software
  • Setup and configuration wizard
  • Displays dimensions, status and weight if scale is directly attached
  • Requires virtually no special alignment or special handling while placing an object under the work area
  • Converts irregular shapes like cylinders, spheres, tubes, polybags and uneven shapes to 0.5 in NTEP Certified cubed dimensions
  • Dimensions flats, less than 1.2 in height, with the use of a scale or flat detection trigger located on the iDimension 100’s base plate
  • Automatic or manual operator modes
  • Automatic operating mode is the standard out of the box configuration which allows you to move the parcel under the work area without the press of a button
  • Manual operating mode is for use with custom or 3rd party software interface that can be triggered by a bar code scanner, software function or demo display when interfaced to a PC
  • Interfaces with most NTEP Certified shipping scales and select Rice Lake indicators
  • Quick assembly: Includes all necessary tools and components for a complete out-of-the-box solution and immediate use with minimal operator training
  • No additional installation of software required on your PC. When connected to a network, the embedded firmware provides access to additional displays and configuration parameters
  • Connect to a PC and communicate directly over the network via static IP or DCHP. Use our open web service interface to take advantage of additional built in features like; a low resolution image of each dimension weight and more.
    Specifications
  • Calculates dimensions in less than 0.2 seconds
  • Instantly captures dimensions and weight data as well as an image of static items
  • Dimensions packages (NTEP/OIML), flats and irregular shapes with ease
  • Converts irregular objects like cylinders, spheres, tubes, polybags and uneven objects into accurate, cubed dimensions
  • Industrial-grade construction with no moving parts
  • No dangerous lasers are used for workplace safety
  • Requires virtually no special placement or handling while setting the object under the work area
  • Automatic or Manual operating modes
  • Manual Mode: Initiate dimensioning of an item via barcode scan or software function key
  • Automatic Mode: Initiate dimensioning of an item via detection in work area
  • Interfaces with most shipping scales and select Rice Lake indicators
  • Designed for complete peripheral setup with included USB port for monitor interface and additional USB port for interfacing to a single scale, mouse, keyboard or USB hub to connect multiple devices
  • Quick assembly with necessary tools included
  • DHCP IP address web service and free API to interface with the system using a simple HTTP request and XML parsing method
  • Easy to set up and calibrate with the included calibration object and embedded web service interface via a fixed IP or DHCP
