DIGI ® DC-788 Series Industrial Counting Scales
Doing More for Less. Th e DIGI DC-788 exceeds all expectations of a counting scale—at a price point that can’t be beat! With a capacity of up to 100 pounds, and a rechargeable battery that provides up to 24 hours of continuous usage, this durable counting scale offers tremendous power and virtually unlimited fl exibility. Its bright red LCD display can be seen from virtually any angle and is highly visible in low light areas. Only non-counting applications are NTEP approved.
Accurate Simplicity
If accuracy and ease-of-use are important, the DC-788 is a must-have. With its RS-232 interface, you can easily attach a scanner or printer for all your labeling applications. And only the DC-788 allows you to customize your output by disabling specifi c spec codes. With the DC-788’s increased capacity and power, you can now do much more for a lot less!
STANDARD FEATURES
- Counting resolution of 1,000,000
- Auto-recomputing function
- Negative sampling and counting (count out of a full container)
- Bright red LCD display is easily readable from virtually any angle
- Simultaneous weight display, unit weight, tare, and quantity
- Net/gross weight display
- Lb/kg weight display conversion
- RS-232 output to PC or printer
- AC or rechargeable battery operation (battery optional)
- 100 product look-up registers
- NTEP approved for non-counting applications (10 lb and larger)
|
|
|
| Model |
DC-788-2 |
DC-788-10 |
DC-788-25 |
DC-788-50 |
DC-788-100 |
| 88928 |
88929 |
88930 |
88931 |
88932 |
$765.00
|
$765.00
|
$765.00
|
$765.00
|
$765.00
|
Capacity
Readability |
2 x 0.0002 lb |
10 x 0.002 lb |
25 x 0.005 lb |
50 x 0.01 lb |
100 x 0.02 lb |
| 1 x 0.0001 kg |
5 x 0.001 kg |
10 x 0.002 kg |
25 x 0.005 kg |
50 x 0.01 kg |
| Pan Size |
7 x 10 in |
10 x 13 in |
10 x 13 in |
10 x 13 in |
10 x 13 in |
| Legal For Trade |
- |
NTEP CC 07-015
Class III for weigh mode only |
| Internal Resolution |
1/1,000,000 |
| Weight Display Resolution |
1/5,000 NTEP, other selections capacity dependent |
| Display |
Liquid crystal display (LCD)
Weight: 5-digit
Unit weight: 5-digit
Quantity: 7-digit
Tare: 5-digit |
| Power Source Consumption |
AC: 115, 60 Hz
Optional battery: 6 V, 5.0 Ah |
| Printer Compatibility |
DT4
Epson® TM-U220 tape
STAr SP512 tape
Epson TM-U295 ticket |
| Number of Scale Channels |
One remote scale, one 350 Ù load cell |
| Zero Adjust Range |
+127% full scale |
| Memory Items |
100 |
| Computer Interface |
RS-232 DB-9M connection |
| Battery Operation |
24 hours of continuous usage (battery optional) |
| Charge Time: |
8-10 hours (battery optional) |
| Operating Temperature |
14º F to 104º F (-10º C to 40º C) |
| Dimensions |
Overall (W x D x H): 14 x 13.75 x 4.5 in (354 x 349 x 115 mm) |
| Warranty |
Two-year limited warranty |
|
